A patient with severe, symptomatic aortic stenosis is referred to the structural heart team. Transcatheter Aortic Valve Replacement (TAVR) is on the table, but success hinges on meticulous preprocedural planning. Accurate measurements of the aortic annulus, coronary ostia height, and the entire vascular access route are non-negotiable. The team needs to decide on the optimal initial imaging to acquire this data, balancing diagnostic yield with patient factors like renal function and radiation exposure. This guide clarifies the American College of Radiology (ACR) recommendations to ensure the right first study is ordered.

What Does ACR Preprocedural Planning for Transcatheter Aortic Valve Replacement Cover?

This ACR topic focuses specifically on the initial, non-invasive imaging required for patients who are candidates for TAVR. The criteria are divided into two primary clinical scenarios that reflect the key anatomical assessments needed for a successful procedure:

• Aortic Root Assessment: Evaluating the detailed anatomy of the aortic valve complex, including the annulus, leaflets, sinus of Valsalva, and the position of the coronary arteries. This is critical for selecting the correct valve size and type and for predicting the risk of complications like coronary obstruction.
• Vascular Access Assessment: Evaluating the entire arterial path from the thoracic aorta down to the femoral arteries. This is essential for determining the feasibility of a transfemoral approach and identifying potential challenges like vessel tortuosity, calcification, or small luminal diameter that might necessitate an alternative access site (e.g., subclavian, transapical, transcaval).

These guidelines do not cover the initial diagnosis of aortic stenosis (which often relies on transthoracic echocardiography), post-procedural surveillance imaging, or the evaluation of other valvular heart diseases.

What Imaging Should I Order for Preprocedural Planning for Transcatheter Aortic Valve Replacement? Recommendations by Clinical Scenario

The ACR provides specific guidance for the two key phases of TAVR planning. The choice of imaging depends on the anatomical region being assessed.

For the first scenario, preintervention planning for transcatheter aortic valve replacement: assessment of aortic root, several modalities are considered Usually Appropriate. The workhorse is CT heart function and morphology with IV contrast, which provides exquisite, multiplanar detail of the aortic annulus for precise sizing. It also clearly delineates the relationship between the annulus and the coronary ostia. Also rated Usually Appropriate are US echocardiography transesophageal (TEE) and MRI heart function and morphology (with or without IV contrast). TEE offers excellent real-time visualization, while MRI is a superb non-radiation alternative, especially in patients with contraindications to iodinated contrast, though it may be less available or have longer acquisition times. Transthoracic echocardiography (TTE) is rated Usually Not Appropriate for this specific planning purpose, as it lacks the spatial resolution for the precise measurements required.

For the second scenario, preintervention planning for transcatheter aortic valve replacement: assessment of supravalvular aorta and vascular access, CT angiography is the dominant modality. A CTA chest abdomen pelvis with IV contrast is rated Usually Appropriate and is the standard of care. This single acquisition provides a complete roadmap of the aorta and iliofemoral system, allowing for detailed assessment of vessel diameter, tortuosity, and calcification burden. Standalone CTA chest with IV contrast and CTA abdomen and pelvis with IV contrast are also Usually Appropriate. In patients with severe renal dysfunction or contrast allergy, MRA chest abdomen pelvis with IV contrast or MRA of the individual regions are considered May be Appropriate alternatives. Invasive studies like aortography are Usually Not Appropriate for initial planning.

ACR Imaging Recommendations Table

Adult vs. Pediatric Preprocedural Planning for Transcatheter Aortic Valve Replacement Imaging: Radiation Dose Tradeoffs

While TAVR is predominantly performed in an elderly population for degenerative aortic stenosis, it is occasionally considered in younger patients with congenital or other specific valve pathologies. In these cases, minimizing cumulative radiation exposure is a critical consideration. The ACR guidelines reflect this through different Relative Radiation Level (RRL) estimates for pediatric patients, adhering to the As Low As Reasonably Achievable (ALARA) principle.

For CT-based studies, the pediatric RRLs are consistently lower than their adult counterparts (e.g., 3-10 mSv for a pediatric cardiac CT vs. 10-30 mSv for an adult). This difference underscores the use of size- and weight-based protocols to reduce dose. For the pediatric population, the value of non-ionizing radiation modalities like MRI and echocardiography is amplified. Although MRI may have logistical challenges, its lack of radiation makes it a highly attractive option for aortic root assessment in younger TAVR candidates when available and clinically appropriate.

Imaging Protocol Details for Preprocedural Planning for Transcatheter Aortic Valve Replacement

Once you’ve decided on the right study, the specific imaging protocol is critical for obtaining the necessary diagnostic information. A TAVR-protocol CT, for example, requires precise ECG gating and contrast timing to minimize motion artifact and optimize visualization of the aortic root and coronary arteries. Our protocol guides cover technique, contrast, and interpretation principles for the studies recommended above:

• CT Chest/Abdomen/Pelvis with IV Contrast

Tools to Help You Order the Right Study

Selecting the most appropriate imaging study involves synthesizing clinical data, patient factors, and established guidelines. To streamline this process, GigHz provides a suite of decision-support resources for clinicians.

The ACR Appropriateness Criteria Lookup tool allows you to quickly search the full ACR guidelines for thousands of clinical scenarios beyond TAVR planning. When you need to understand the technical specifics of a chosen study, the Imaging Protocol Library offers detailed, step-by-step guides. For discussions with patients about radiation, the Radiation Dose Calculator helps quantify and communicate exposure risks from single and cumulative imaging procedures.

Frequently Asked Questions

Why is CT the most common imaging modality for TAVR planning?

CT angiography (CTA) has become the gold standard for TAVR planning because it provides a comprehensive, high-resolution, three-dimensional dataset in a single, fast acquisition. It allows for precise, reproducible measurements of the aortic annulus, coronary artery height, and the entire vascular access route from the chest to the groin. This level of detail is crucial for accurate device sizing and minimizing procedural complications.

Can MRI be used as the sole imaging modality for TAVR planning?

Yes, MRI can be used for TAVR planning, and it is rated as “Usually Appropriate” by the ACR for aortic root assessment. Its primary advantage is the lack of ionizing radiation and its ability to be performed without iodinated contrast (though gadolinium-based contrast is often used). However, it is less commonly used as the sole modality due to longer scan times, higher cost, more limited availability, and potential for artifacts. It is an excellent alternative for patients with severe renal failure or a severe allergy to iodinated contrast.

Why is a standard transthoracic echocardiogram (TTE) not sufficient for TAVR planning?

While a TTE is essential for the initial diagnosis and grading of aortic stenosis, it is rated “Usually Not Appropriate” by the ACR for the specific task of preprocedural planning. TTE is a 2D imaging technique and lacks the spatial resolution to provide the precise, multiplanar 3D measurements of the aortic annulus and vascular access pathways that are required for selecting the correct valve size and planning a safe delivery route.

What is the purpose of assessing the entire aorta and iliofemoral arteries?

The default and least invasive approach for TAVR is transfemoral, where the new valve is delivered via a catheter inserted into the femoral artery in the groin. Assessing the entire path from the femoral artery up to the aortic valve is critical to ensure the delivery system can pass safely. The CTA evaluates vessel diameter (is it large enough?), tortuosity (are there too many sharp bends?), and the amount of calcification (which can increase the risk of vessel injury or dissection).

When is a transesophageal echocardiogram (TEE) used in the TAVR process?

A TEE is rated “Usually Appropriate” for preprocedural aortic root assessment and can provide excellent anatomical detail. However, its main role is often intraprocedural. During the TAVR procedure itself, TEE is frequently used for real-time guidance, helping to position the valve accurately and immediately assess for complications like paravalvular leak, aortic dissection, or pericardial effusion.
