It’s late in a busy shift, and you are evaluating a young child with a concerning history or physical exam findings. The possibility of non-accidental trauma is raised, a high-stakes clinical scenario requiring a meticulous and evidence-based approach. Deciding on the appropriate initial imaging is a critical first step, balancing the need for a comprehensive evaluation against the risks of radiation exposure in a vulnerable patient. Do you start with a skeletal survey, a focused CT, or both? The American College of Radiology (ACR) provides clear, consensus-driven guidance to navigate these difficult decisions. This article breaks down the ACR Appropriateness Criteria for suspected physical abuse in a child, helping you order the right study with confidence.
What Does ACR Suspected Physical Abuse-Child Cover?
The ACR Appropriateness Criteria for Suspected Physical Abuse-Child focus on the initial imaging evaluation for children when there is a concern for non-accidental trauma. The guidelines are stratified by patient age (typically with a cutoff at 24 months) and the specific clinical presentation, such as concern for occult injury without localizing signs, suspected Central Nervous System (CNS) injury, or suspected visceral injury. These criteria are designed to guide the initial diagnostic workup when injuries are not clinically apparent.
This topic does not cover the imaging of obvious, clinically apparent injuries (e.g., an open fracture), which would be imaged based on their specific presentation. It also does not detail long-term follow-up imaging protocols beyond the initial 10-14 day period. The primary goal is to provide a standardized, high-yield approach to detecting occult injuries—such as classic metaphyseal lesions, rib fractures, and intracranial hemorrhage—that are highly specific for abuse. The recommendations are tailored to maximize diagnostic sensitivity while adhering to the principles of As Low As Reasonably Achievable (ALARA) for radiation dose.
What Imaging Should I Order for Suspected Physical Abuse-Child? Recommendations by Clinical Scenario
Imaging recommendations for suspected pediatric physical abuse are highly dependent on the child’s age and clinical findings. The ACR guidelines provide a structured framework for these scenarios.
For a child 24 months of age or younger with a general concern for physical abuse but no clinically apparent injuries, the ACR rates both a Radiography skeletal survey and a CT head without IV contrast as Usually appropriate. This combination is the cornerstone of evaluation in this age group, designed to detect occult skeletal and intracranial injuries, which are common and may be clinically silent. A skeletal survey is essential for identifying high-specificity fractures. For more details on this exam, see our Skeletal Survey protocol guide.
In contrast, for a child greater than 24 months of age with a similar non-specific concern, the approach shifts. A Radiography of the area of interest is rated as Usually appropriate, while a full skeletal survey is downgraded to May be appropriate (Disagreement). This change reflects that older, ambulatory children are more likely to have accidental trauma, and abuse-related fractures are less common. Imaging is therefore more focused on clinically suspected areas.
When there are clinical findings suspicious for CNS injury (e.g., neurologic signs, scalp hematoma) in a child 24 months or younger, a CT head without IV contrast and a Radiography skeletal survey are both Usually appropriate. For children older than 24 months with suspected CNS injury, a CT head without IV contrast remains Usually appropriate, along with a focused Radiography of the area of interest.
If visceral injury is suspected due to findings like abdominal bruising or pain, a CT abdomen and pelvis with IV contrast is Usually appropriate for all ages. In children 24 months or younger, a Radiography skeletal survey is also Usually appropriate to screen for co-existing occult fractures. For children older than 24 months, a focused Radiography of the area of interest is preferred.
For follow-up imaging in a child 24 months or younger with a negative initial workup, a repeat Radiography skeletal survey in 10-14 days is Usually appropriate to detect healing fractures that were initially occult.
Finally, for an asymptomatic child 24 months or younger who lives with another child with known or suspected abuse, a screening Radiography skeletal survey is considered Usually appropriate to assess for occult injury.
ACR Imaging Recommendations Table
| Clinical Scenario | Top Procedure(s) | ACR Rating | Adult RRL | Pediatric RRL |
|---|---|---|---|---|
| Child ≤24 mo. Concern for abuse, no clinically apparent injuries. Initial imaging. | Radiography skeletal survey; CT head without IV contrast | Usually appropriate | ☢ ☢ ☢ 1-10 mSv | ☢ ☢ ☢ 0.3-3 mSv [ped] |
| Child >24 mo. Concern for abuse, no clinically apparent injuries. Initial imaging. | Radiography area of interest | Usually appropriate | Varies | Varies |
| Child ≤24 mo. Suspicious for CNS injury. Initial imaging. | Radiography skeletal survey; CT head without IV contrast | Usually appropriate | ☢ ☢ ☢ 1-10 mSv | ☢ ☢ ☢ 0.3-3 mSv [ped] |
| Child >24 mo. Suspicious for CNS injury. Initial imaging. | Radiography area of interest; CT head without IV contrast | Usually appropriate | Varies | Varies |
| Child ≤24 mo. Suspicious for visceral injury. Initial imaging. | Radiography skeletal survey; CT abdomen and pelvis with IV contrast | Usually appropriate | ☢ ☢ ☢ 1-10 mSv | ☢ ☢ ☢ ☢ 3-10 mSv [ped] |
| Child >24 mo. Suspicious for visceral injury. Initial imaging. | Radiography area of interest; CT abdomen and pelvis with IV contrast | Usually appropriate | Varies | Varies |
| Child ≤24 mo. Negative initial survey/CT. Follow-up imaging (10-14 days). | Radiography skeletal survey | Usually appropriate | ☢ ☢ ☢ 1-10 mSv | ☢ ☢ ☢ 0.3-3 mSv [ped] |
| Child ≤24 mo. Asymptomatic, household contact of abused child. Initial imaging. | Radiography skeletal survey | Usually appropriate | ☢ ☢ ☢ 1-10 mSv | ☢ ☢ ☢ 0.3-3 mSv [ped] |
Adult vs. Pediatric Suspected Physical Abuse-Child Imaging: Radiation Dose Tradeoffs
The topic of suspected physical abuse is exclusively pediatric, but the principles of radiation safety and age-based protocoling are paramount. The ACR guidelines highlight a critical age cutoff at 24 months, which significantly alters the imaging algorithm. For infants and toddlers (≤24 months), a full skeletal survey is the standard of care for an initial abuse workup. This is because young, non-ambulatory children have a higher incidence of occult fractures, and certain fracture patterns (like classic metaphyseal lesions) are highly specific for non-accidental trauma. Their inability to provide a history or localize pain makes a comprehensive skeletal evaluation necessary.
For children older than 24 months, the recommendations shift from a comprehensive survey to focused radiographs of a specific area of concern. This change reflects both a different pattern of injury and a heightened consideration for cumulative radiation dose. Older children are more likely to sustain accidental injuries, and a complete skeletal survey has a lower diagnostic yield for abuse in this population. By limiting imaging to symptomatic or suspicious areas, clinicians can significantly reduce the overall radiation exposure while still targeting the evaluation effectively. This approach is a direct application of the ALARA principle, tailoring the diagnostic workup to the pretest probability of disease and minimizing potential long-term risks.
Imaging Protocol Details for Suspected Physical Abuse-Child
Once you’ve decided on the right study based on the clinical scenario, ensuring it is performed and interpreted correctly is the next critical step. The technical details of the imaging protocol—from the number of radiographic views to the CT slice thickness—can directly impact diagnostic accuracy. Our protocol guides provide concise, actionable details on technique, contrast administration, and key interpretation principles for the studies recommended in these ACR criteria.
Tools to Help You Order the Right Study
Navigating complex imaging guidelines can be challenging, especially in time-sensitive situations. GigHz offers a suite of reference tools designed to support evidence-based clinical decisions at the point of care.
For scenarios not covered here, the ACR Appropriateness Criteria Lookup provides a fast, searchable interface to the complete ACR guidelines, covering thousands of clinical variants across all specialties. It helps you find the official ACR recommendation for your specific patient presentation in seconds.
Once an imaging study is chosen, our Imaging Protocol Library offers detailed, step-by-step protocols for hundreds of common and advanced imaging procedures. These guides are essential for ensuring the chosen study is performed to the highest standard for optimal diagnostic quality.
To help with patient communication and tracking radiation exposure, the Radiation Dose Calculator allows you to estimate effective dose for various imaging studies. This tool is invaluable for discussing the risks and benefits of imaging with families and for maintaining ALARA principles in your practice.
Why is a skeletal survey recommended for children under 24 months but not always for older children?
A skeletal survey is standard for children under 24 months because they have a higher incidence of occult (clinically hidden) fractures in cases of abuse. Fracture patterns like classic metaphyseal lesions and posterior rib fractures are highly specific for non-accidental trauma and are often found in asymptomatic infants. In children older than 24 months, accidental trauma is more common, the diagnostic yield of a full survey is lower, and a more focused radiographic approach is generally preferred to limit radiation.
When is MRI preferred over CT for suspected head injury in a child?
CT of the head without contrast is the primary imaging modality for acute suspected head injury because it is fast, widely available, and excellent for detecting acute hemorrhage and skull fractures. MRI may be considered as a follow-up study or in subacute settings to better characterize the age of hemorrhages, detect non-hemorrhagic shearing injuries (diffuse axonal injury), and evaluate for hypoxic-ischemic injury. However, it is not the first-line study in an acute workup due to longer acquisition time and the need for sedation in young children.
What is the purpose of a follow-up skeletal survey 10-14 days after a negative initial one?
Some subtle, non-displaced fractures may not be visible on the initial radiographs. After 10-14 days, the body’s healing response creates a callus (new bone formation) around the fracture site, which makes the fracture line more conspicuous on a repeat radiograph. A follow-up survey can therefore increase the sensitivity for detecting occult fractures that were missed on the initial study.
Why is CT with IV contrast used for suspected visceral injury?
Intravenous contrast enhances the solid organs (like the liver, spleen, and kidneys) and blood vessels, allowing for much better detection of injuries such as lacerations, hematomas, and active bleeding. A non-contrast CT is much less sensitive for these types of visceral injuries. Given that blunt abdominal trauma is a significant cause of morbidity and mortality in child abuse, a contrast-enhanced CT is essential when this is suspected.
Are there any radiation-free alternatives for the initial abuse workup?
While ultrasound and MRI are radiation-free, they have specific, limited roles in the initial abuse workup. Ultrasound of the abdomen may be used in some centers as a screening tool but is less sensitive than CT for many visceral injuries. Head ultrasound can be used in infants with an open fontanelle but is inferior to CT for detecting many types of intracranial injury. MRI is excellent for brain and spine detail but is not the first-line test for acute head trauma. For detecting skeletal fractures, radiography (the skeletal survey) remains the gold standard, as MRI and ultrasound are not sensitive for the complete range of fractures seen in abuse.
