CTA Coronary Arteries (CCTA) — Dictation, Appropriateness, and Dose for Residents
The CCTA from the ED just hit your list. Low-to-intermediate risk chest pain, negative troponins, but the team wants to rule out coronary artery disease before discharge. Your attending expects a perfect CAD-RADS 2.0 classification for every segment, a comment on plaque characteristics, and a definitive statement on any anomalous origins. Getting the heart rate down is the tech’s job; getting the report right is yours.
When I was a fellow, the CCTA was one of the most intimidating studies to read solo. The anatomy is complex, the potential for motion artifact is high, and the clinical stakes are even higher. You need a systematic approach and a rock-solid template. Let’s build one that will make you look like a pro, every time. For more guides like this, check out our free residents and fellows resource hub.
What a CTA Coronary Arteries (CCTA) Covers and What Attendings Look For
A Coronary CT Angiography (CCTA) is a non-invasive study designed to visualize the coronary arteries. Unlike a simple calcium score, which only quantifies calcified plaque, a CCTA provides a detailed anatomic roadmap of the coronary tree, bypass grafts, and stents. It’s the go-to for evaluating low-to-intermediate risk chest pain, suspected coronary anomalies, and for pre-procedural planning like TAVR.
Your attending is looking for a comprehensive, structured report that answers these key questions:
- Coronary Anatomy & Dominance: Is the patient right, left, or co-dominant? Are there any anomalous origins or courses (especially a malignant interarterial course)?
- Plaque Burden & Stenosis: What is the overall calcium score? For each major vessel and branch, what is the degree of stenosis? This must be graded using the CAD-RADS 2.0 classification (0-5).
- Plaque Characteristics: Is the plaque calcified, non-calcified, or mixed? Are there high-risk “vulnerable plaque” features like positive remodeling, low attenuation, or spotty calcifications?
- Grafts and Stents: If present, are bypass grafts patent or occluded? Are stents patent, and is there evidence of in-stent restenosis?
- Non-Coronary Findings: Don’t forget the rest of the chest. Is there an incidental pulmonary embolism (especially on a triple-rule-out), aortic dissection, pericardial effusion, or lung nodule?
- Functional Significance: If FFR-CT is performed, what are the values? A value ≤0.75 is abnormal and suggests hemodynamically significant stenosis.
Radiology Report Template for CTA Coronary Arteries (CCTA)
This template provides a reliable skeleton. Dictate your positive findings, and let the structure guide you through a complete report. Remember the key principles: systematic evaluation of each vessel, consistent use of CAD-RADS, and a thorough search for non-coronary pathology.
Technique
ECG-gated contrast-enhanced images of the heart were acquired using a [prospective ECG-triggered/retrospective ECG-gated] technique. The patient’s heart rate during the scan was [X] bpm. [X] mL of [Contrast Agent] was administered intravenously. Multiplanar reformatted images were reviewed on a dedicated 3D workstation.
Clinical Indication: [e.g., Chest pain, evaluation for coronary artery disease]
Comparison: [e.g., Chest radiograph from YYYY-MM-DD]
Findings
Agatston Calcium Score: [e.g., 150 (moderate plaque burden, 75th percentile for age/sex)] or [Not performed].
Coronary Artery Dominance: [Right / Left / Co-dominant] circulation.
Coronary Artery Anatomy: Normal origin and course of the coronary arteries. [Or describe anomaly, e.g., Anomalous origin of the right coronary artery from the left coronary sinus with a malignant interarterial course between the aorta and pulmonary artery.]
Left Main Coronary Artery: [e.g., Patent with no significant stenosis. Calcified plaque without significant stenosis.]
Left Anterior Descending Artery (LAD):
Proximal LAD: [e.g., Mild (25-49%) stenosis due to mixed plaque.]
Mid LAD: [e.g., Minimal (<25%) stenosis due to noncalcified plaque.]
Distal LAD: [e.g., Patent.]
Diagonal Branches: [e.g., D1 has moderate (50-69%) proximal stenosis. D2 is patent.]
Left Circumflex Artery (LCx):
Proximal LCx: [e.g., Patent.]
Obtuse Marginal Branches: [e.g., OM1 is a small caliber vessel and is patent.]
Right Coronary Artery (RCA):
Proximal RCA: [e.g., Severe (70-99%) stenosis due to heavily calcified plaque.]
Mid RCA: [e.g., Patent.]
Distal RCA (including PDA/PLV): [e.g., Patent.]
Bypass Grafts: [e.g., LIMA to LAD graft is widely patent. Saphenous vein graft to the obtuse marginal is occluded proximally.]
Coronary Stents: [e.g., Stent in the proximal LAD is patent without evidence of in-stent restenosis.]
Cardiac and Extracardiac Structures:
Myocardium and Ventricles: Normal left ventricular size and wall thickness. No regional wall motion abnormalities appreciated on this non-functional study.
Pericardium: No pericardial effusion.
Aorta: Thoracic aorta is normal in caliber. No dissection or aneurysm.
Pulmonary Arteries: Main pulmonary artery is normal in caliber. No evidence of central pulmonary embolism.
Lungs: [e.g., Clear. No suspicious nodules or consolidation.]
Other: [e.g., Small hiatal hernia.]
Impression
- Coronary artery disease with the most severe stenosis being [e.g., severe (70-99%) stenosis of the proximal right coronary artery due to calcified plaque].
- [e.g., Moderate (50-69%) stenosis of the proximal first diagonal branch.]
- [e.g., Patent LIMA to LAD bypass graft.]
- No evidence of hemodynamically significant stenosis in the left main, LAD, or circumflex systems.
- Overall CAD-RADS Assessment: 4A (Severe stenosis >70% in at least one vessel, no high-risk plaque).
Free Template Sources for Your On-Call Toolkit
Building a personal library of templates is a rite of passage in residency. But you don’t have to start from scratch. Beyond your institution’s shared macros, two great free repositories exist that are curated by radiologists for radiologists.
- RadReport.org: Maintained by the RSNA, this is the most comprehensive library of peer-reviewed templates, covering nearly every modality and subspecialty. It’s a fantastic starting point for standardized, best-practice reporting.
- Radiology Templates (AU): This Australian-maintained site offers another excellent collection of free, practical templates. The formatting is clean and they often have useful variations for common clinical scenarios.
The Next-Level Move: From Free-Form Dictation to Structured Report
A good template is your safety net, ensuring you don’t miss key elements. But the real friction on call isn’t finding the template; it’s populating it accurately and efficiently while the call list keeps growing. This is where AI-assisted reporting tools can make a significant difference.
Instead of manually navigating a template, you can dictate your positive findings in free form—”severe calcific stenosis in the prox RCA, moderate mixed plaque in the D1″—and let the software handle the rest. Tools like GigHz Precision AI are designed to parse that clinical language and automatically generate a fully structured report using pre-loaded ACR and SIR templates. This approach helps streamline the reporting process, ensuring that classifications like CAD-RADS are applied consistently. It also supports the integration of Clinical Decision Support (CDS), which can prompt for necessary classifications when specific findings are dictated, helping to ensure reports are complete and actionable.
When Should You Order a CTA Coronary Arteries? ACR Appropriateness Criteria
The American College of Radiology (ACR) provides evidence-based guidelines to help clinicians choose the right test for the right patient. For CCTA, the indications are quite specific.
For a patient presenting with acute chest pain but a low to intermediate probability of acute coronary syndrome, CCTA is “Usually Appropriate” as an initial imaging study, especially after an initial negative workup. However, for patients with a high probability of ACS, the ACR guidelines also rate CCTA as “Usually Appropriate,” often as part of a “triple rule-out” protocol, though direct invasive angiography is also a primary option.
In the setting of chronic, stable chest pain with a low to intermediate probability of coronary artery disease, CCTA is also “Usually Appropriate” and is often the preferred first-line anatomic test. For evaluating suspected coronary artery anomalies in adults, CCTA is the definitive non-invasive modality and is rated “Usually Appropriate.”
It’s also a cornerstone of pre-procedural planning for transcatheter aortic valve replacement (TAVR), where it is “Usually Appropriate” for assessing both the aortic root and the coronary arteries to avoid coronary obstruction during valve deployment.
Conversely, for a truly asymptomatic patient, even with intermediate or high risk factors, a coronary artery calcium (CAC) score is often preferred over a full CCTA for risk stratification alone.
How Much Radiation Does a CTA Coronary Arteries Deliver?
A CCTA delivers an estimated effective radiation dose of 3-10 mSv. This places it in the moderate dose tier, equivalent to several years of natural background radiation. The final dose is highly dependent on the specific protocol used, patient body habitus, and, most importantly, the ECG-gating technique.
Dose-reduction strategies are critical. The most effective is using prospective ECG-triggering (a “step-and-shoot” method) instead of retrospective helical gating. Prospective triggering dramatically lowers the dose but requires a slow, regular heart rate (ideally <65 bpm). Retrospective gating is necessary for patients with irregular or fast heart rates but comes with a higher radiation penalty. Modern scanners also use iterative reconstruction algorithms and tube current modulation to further minimize dose while preserving image quality.
| Imaging Study | Typical Effective Dose |
|---|---|
| Natural Background Radiation (1 year) | ~3 mSv |
| CTA Coronary Arteries | 3-10 mSv |
| CT Chest (PE Protocol) | 5-10 mSv |
| Invasive Coronary Angiography | 5-15 mSv |
CTA Coronary Arteries Imaging Protocol — Phases, Contrast, and Reconstructions
The success of a CCTA hinges on a meticulous protocol. The goal is to achieve dense, uniform opacification of the coronary arteries during a quiescent phase of the cardiac cycle, typically mid-to-late diastole. This requires precise heart rate control, sublingual nitroglycerin for vasodilation, and perfect contrast bolus timing.
The table below outlines a typical CCTA protocol. Note the emphasis on fast gantry rotation and thin-slice acquisition to achieve high temporal and spatial resolution.
| Phase / Sequence | Contrast | Key Parameters | Purpose |
|---|---|---|---|
| Topogram | None | kVp: 120 | Scan planning |
| Calcium Score (Optional) | None | Prospective ECG-triggering, 3 mm slices | Quantify calcified plaque burden (Agatston score) |
| Test Bolus / Bolus Tracking | 10-20 mL contrast + saline | ROI in ascending aorta or LV | Determine patient-specific circulation time |
| Coronary Arterial Phase | 60-90 mL @ 5-7 mL/s + saline chase | Prospective or Retrospective ECG-gating, kVp 100-120 (auto-modulated), 0.5-0.625 mm slices | Anatomic imaging of the coronary arteries |
Common protocol pitfalls: The most common failure point is inadequate heart rate control. A heart rate over 65-70 bpm often results in motion artifact that can render segments uninterpretable. The second pitfall is mistiming the contrast bolus, leading to suboptimal opacification. Using a test bolus or automated bolus tracking is essential. Finally, choosing the wrong gating strategy is a classic error. For a patient with a regular heart rate under 65 bpm, prospective triggering is preferred to lower radiation dose. For a patient with an irregular rhythm like atrial fibrillation, retrospective gating is required to allow for reconstruction of different cardiac phases, albeit at a higher dose.
