Obstetric and Gynecologic Imaging

How Should You Image Fetal Discordance in a Multiple Gestation Pregnancy? An ACR Workflow

·
How Should You Image Fetal Discordance in a Multiple Gestation Pregnancy? An ACR Workflow

It’s late in the afternoon clinic, and you are reviewing the results of a routine 30-week growth scan for a patient with a monochorionic-diamniotic twin pregnancy. The sonographer’s report flags a significant discordance: an estimated fetal weight difference of 25% and a striking disparity in amniotic fluid volumes between the two sacs. You now face the critical task of differentiating between several serious, time-sensitive conditions unique to multiple gestations. The immediate clinical question is which specific imaging studies are necessary to assess fetal well-being, clarify the diagnosis, and guide management. For this scenario, the American College of Radiology (ACR) Appropriateness Criteria rate US duplex Doppler fetal middle cerebral artery as Usually Appropriate to evaluate the hemodynamic status of the fetuses.

Who Fits This Clinical Scenario for Multiple Gestations?

This guidance applies to patients with a confirmed multiple gestation—including dichorionic, monochorionic, or higher-order multiples—where a known abnormality or discordance has been identified during antepartum surveillance. The key trigger for this workflow is the presence of a discrepancy between the fetuses, such as differences in amniotic fluid volume, estimated fetal weight, or overall size. This is a problem-focused evaluation, not a routine screening examination.

This clinical workflow is specifically for situations where you are actively investigating a known issue. It should be distinguished from other related scenarios:

  • Exclusion 1: Routine, Uncomplicated Growth Surveillance. If you are performing scheduled growth and well-being checks in an otherwise uncomplicated dichorionic or monochorionic twin pregnancy without known discordance, you would refer to the standard surveillance guidelines. This scenario is for when that surveillance uncovers a problem.
  • Exclusion 2: Initial First-Trimester Assessment. If you are performing the initial ultrasound to determine the number of fetuses, chorionicity, and amnionicity in the first trimester, that represents a different clinical question with its own imaging pathway.
  • Exclusion 3: Second-Trimester Anatomic Survey. While the detailed anatomic survey may be the point at which discordance is first suspected, the primary goal of that examination is different from the focused hemodynamic and growth assessment discussed here.

This article is for the clinician who has already identified a red flag and needs to order the appropriate next steps to work up the cause.

What Diagnoses Are You Working Up with Fetal Discordance?

When faced with discordant growth or fluid in a multiple gestation, you are evaluating for several high-stakes conditions that can significantly impact fetal outcomes. The choice of imaging is driven by the need to differentiate among these possibilities.

Selective Fetal Growth Restriction (sFGR)
This is a primary consideration, particularly in monochorionic pregnancies where unequal sharing of the placenta can lead to one fetus receiving insufficient nutrients. sFGR is defined by a small estimated fetal weight in one fetus and significant weight discordance between the twins. Doppler assessment of the umbilical artery is crucial for staging sFGR and predicting outcomes, but assessing for signs of fetal compensation or decompensation with other vessels is also key.

Twin-to-Twin Transfusion Syndrome (TTTS)
A serious complication of monochorionic pregnancies, TTTS results from unbalanced blood flow between fetuses through placental vascular connections. It classically presents with a combination of oligohydramnios (low amniotic fluid) in the “donor” twin and polyhydramnios (high amniotic fluid) in the “recipient” twin. While fluid assessment is diagnostic, Doppler studies are essential for evaluating the cardiovascular impact on both fetuses.

Twin Anemia Polycythemia Sequence (TAPS)
TAPS is a more subtle, chronic form of inter-twin transfusion characterized by a large hemoglobin difference between the fetuses without the classic oligo-polyhydramnios sequence of TTTS. The donor twin becomes anemic, while the recipient becomes polycythemic. This diagnosis relies almost entirely on Doppler assessment of the fetal middle cerebral artery peak systolic velocity (MCA-PSV).

Underlying Congenital Anomaly
It is also possible that the discordance is not due to a placental issue but rather an intrinsic problem with one fetus, such as a structural anomaly, genetic syndrome, or congenital infection, that is impeding its growth. A detailed anatomic re-evaluation is often warranted.

Why Is US Duplex Doppler of the Fetal Middle Cerebral Artery the Recommended Study?

In the context of known fetal discordance, a comprehensive ultrasound evaluation is necessary, and specific Doppler assessments provide critical diagnostic and prognostic information that a simple biometry scan cannot. The ACR rates several ultrasound modalities as Usually Appropriate, with the fetal MCA Doppler playing a unique and vital role.

The primary reason US duplex Doppler fetal middle cerebral artery is rated Usually Appropriate is its ability to non-invasively detect fetal anemia. In response to anemia, the fetal brain prioritizes oxygen delivery through vasodilation, which increases the peak systolic velocity (PSV) of blood flow in the MCA. An elevated MCA-PSV is the key diagnostic marker for TAPS and can also indicate severe fetal compromise and impending decompensation in cases of advanced sFGR. This single measurement provides direct insight into the physiologic state of the fetus.

Other Usually Appropriate studies in this scenario work in concert with the MCA Doppler:

  • US duplex Doppler fetal umbilical artery: This assesses placental function and resistance. Abnormal waveforms (absent or reversed end-diastolic flow) are critical for staging sFGR and indicate a high risk of adverse outcomes.
  • US pregnant uterus transabdominal: This is the foundational study for obtaining fetal biometry to calculate estimated fetal weights and confirm discordance, as well as to measure amniotic fluid volumes.
  • US pregnant uterus biophysical profile (BPP): The BPP assesses acute fetal well-being by evaluating fetal tone, movement, breathing, and amniotic fluid, providing a snapshot of the fetus’s current central nervous system status.

Why are other studies rated lower?

  • MRI fetal without IV contrast is rated May be appropriate. While it is an excellent problem-solving tool for clarifying complex fetal anatomy, especially suspected brain abnormalities, it is not the first-line modality for assessing the hemodynamic consequences of discordance like TAPS or sFGR. It is typically reserved for cases where ultrasound findings are inconclusive or a specific structural question arises.
  • US assessment for TTTS is also rated May be appropriate. Although essential if TTTS is the leading diagnosis, this specific protocol focuses on the Quintero staging criteria. The broader scenario of “known abnormality or discordance” includes conditions like TAPS or sFGR in dichorionic twins where TTTS is not a consideration, making the more general hemodynamic assessment with MCA and umbilical artery Dopplers more universally applicable.

All recommended and appropriate ultrasound modalities carry a radiation level of 0 mSv, making them the safest imaging options during pregnancy.

What’s Next After Fetal Doppler Studies? Downstream Workflow

The results of the comprehensive ultrasound and Doppler assessment will directly guide the next steps in management, which are often urgent and require multidisciplinary coordination.

  • If the study suggests TAPS (discordant MCA-PSV): This finding requires immediate consultation with a Maternal-Fetal Medicine (MFM) specialist at a center with expertise in fetal therapy. Management options may include expectant management with intensive surveillance, fetal laser surgery to ablate the communicating placental vessels, or preterm delivery, depending on the gestational age and severity.
  • If the study suggests severe sFGR (abnormal umbilical artery Dopplers): The specific type of sFGR and the Doppler findings will determine the management plan. Type I sFGR with persistently forward umbilical artery flow may be managed expectantly with frequent surveillance. Type II or III sFGR with absent or reversed end-diastolic flow indicates severe placental dysfunction and a high risk of fetal demise, often necessitating inpatient admission, administration of antenatal corticosteroids, and consideration for delivery.
  • If the study suggests TTTS: The patient should be referred urgently to a fetal therapy center for evaluation for fetoscopic laser surgery, which is the standard of care for most cases of Stage II-IV TTTS before viability.
  • If studies are reassuring but discordance persists: Even with normal Dopplers, significant growth discordance is an independent risk factor. These pregnancies require continued, frequent surveillance (typically weekly or bi-weekly) with ultrasound, including biometry, fluid checks, Doppler studies, and non-stress testing to monitor for any deterioration.

Pitfalls to Avoid (and When to Get Help)

Navigating discordant multiple gestations requires meticulous attention to detail. Here are common pitfalls to avoid:

  • Failing to obtain MCA Dopplers: In a monochorionic twin pregnancy with discordance, omitting MCA-PSV measurements means you could miss a diagnosis of TAPS.
  • Incorrect Doppler angle: Accurate Doppler measurements require a low angle of insonation (ideally close to 0 degrees). An incorrect angle can lead to falsely high or low velocity measurements, resulting in misdiagnosis.
  • Misinterpreting chorionicity: Management differs drastically between monochorionic and dichorionic twins. If chorionicity is uncertain, every effort should be made to clarify it, including reviewing first-trimester imaging.
  • Delaying referral: The conditions causing fetal discordance can progress rapidly. If findings are concerning for TTTS, TAPS, or severe sFGR, do not delay in escalating care to an MFM specialist or a regional perinatal center.

If you identify abnormal Doppler findings or a significant interval change in growth or fluid, escalate immediately to a Maternal-Fetal Medicine specialist.

Related ACR Topics and Tools

For a comprehensive overview of all clinical scenarios related to imaging multiple gestations, and for tools to assist in ordering and interpreting studies, the following resources are available.

Frequently Asked Questions

Why is Middle Cerebral Artery (MCA) Doppler so important if I already see a big size difference between the twins?

While size difference (biometry) tells you that a growth problem exists, the MCA Doppler provides crucial physiologic information. It helps determine if a fetus is anemic, which is the hallmark of Twin Anemia Polycythemia Sequence (TAPS). It also serves as a key indicator of fetal distress and brain-sparing in severe selective Fetal Growth Restriction (sFGR), helping to guide the timing of delivery.

Does this guidance apply to dichorionic (fraternal) twins as well?

Yes. While conditions like TTTS and TAPS are exclusive to monochorionic (identical) twins who share a placenta, significant growth discordance can still occur in dichorionic twins due to unequal placental implantation or underlying genetic/structural issues in one fetus. The workup to assess fetal well-being, including biometry, amniotic fluid assessment, and Doppler studies, is still essential.

How often should I repeat these ultrasound studies if I find discordance?

The frequency of surveillance depends on the specific diagnosis and its severity. For high-risk conditions like severe sFGR with abnormal umbilical artery Dopplers, monitoring may be required multiple times per week. For more stable discordance with reassuring Dopplers, surveillance is typically performed every 1 to 2 weeks. This decision should be made in consultation with a Maternal-Fetal Medicine specialist.

Is an MRI necessary if the ultrasound shows a significant abnormality?

An MRI is rated as ‘May be appropriate’ and is not a routine part of the initial workup for discordance. It is a problem-solving tool used when ultrasound findings are unclear or when there is a high suspicion of a complex fetal anomaly, particularly involving the brain, that could be better characterized by MRI. The decision to proceed with an MRI should follow a comprehensive ultrasound and consultation with MFM.

What is the difference between Twin-to-Twin Transfusion Syndrome (TTTS) and TAPS?

Both are complications of shared placental circulation in monochorionic twins. TTTS is an issue of blood volume, leading to one twin having too little fluid (oligohydramnios) and the other too much (polyhydramnios). TAPS is an issue of red blood cell concentration, where a slow, unbalanced transfusion leads to one twin becoming severely anemic and the other polycythemic, often without the dramatic fluid changes seen in TTTS. Their diagnostic criteria and sometimes their treatments differ.

Reviewed by Pouyan Golshani, MD, Interventional Radiologist — May 30, 2026
