Pediatric Imaging

What Is the Best Initial Imaging for Suspected Necrotizing Enterocolitis in an Infant?

·
What Is the Best Initial Imaging for Suspected Necrotizing Enterocolitis in an Infant?

A premature infant in the neonatal intensive care unit, born at 28 weeks, develops feeding intolerance and abdominal distension overnight. On exam, the abdomen is tense and tender, and a guaiac test on a small stool sample is positive. The clinical picture is highly suspicious for necrotizing enterocolitis (NEC), a life-threatening condition requiring rapid diagnosis and management. The immediate question for the clinical team is which imaging study to order first to confirm the diagnosis and assess for complications. This article provides a detailed workflow for this specific scenario, based on the American College of Radiology (ACR) Appropriateness Criteria. For this presentation, both an abdominal ultrasound and abdominal radiography are rated as Usually appropriate.

Who Fits This Clinical Scenario for Suspected Necrotizing Enterocolitis?

This guidance applies specifically to infants, most commonly premature neonates, presenting with clinical signs and symptoms suggestive of necrotizing enterocolitis.

Inclusion criteria for this workflow:

  • Patient: Infant or neonate, particularly those with risk factors like prematurity, low birth weight, or congenital heart disease.
  • Clinical Presentation: A constellation of symptoms including feeding intolerance, vomiting (which may be bilious), abdominal distension, tenderness, bloody stools (hematochezia), lethargy, temperature instability, apnea, and bradycardia.

It is crucial to distinguish this scenario from other causes of abdominal pain in young children, which follow different diagnostic pathways.

Exclusion criteria (route to a different workflow):

  • Suspected Intussusception: An older, typically healthy infant (3 months to 3 years) with paroxysmal, colicky abdominal pain, drawing up of the legs, and potentially a palpable abdominal mass or “currant jelly” stool. This presentation follows the ACR variant for suspected intussusception.
  • Suspected Bowel Obstruction: A child with bilious emesis and abdominal distension, where diagnoses like malrotation with volvulus or intestinal atresia are higher on the differential. While there is overlap, the primary workup may differ.
  • Suspected Constipation: An older infant or toddler with a history of infrequent, hard stools and less acute systemic symptoms. This is a distinct clinical problem with its own imaging guidelines.

What Diagnoses Are You Working Up in an Infant with Suspected NEC?

When ordering initial imaging for suspected NEC, you are evaluating for a specific set of urgent and emergent conditions. The differential diagnosis guides what radiologists look for and what clinicians must be prepared to manage.

Necrotizing Enterocolitis (NEC)
This is the primary diagnosis of concern. NEC is an inflammatory disease leading to ischemic necrosis of the intestinal mucosa. It most commonly affects the terminal ileum and proximal colon. Imaging is critical to confirm the diagnosis by identifying pathognomonic signs like pneumatosis intestinalis (gas within the bowel wall) or portal venous gas, and to assess for the most feared complication: perforation.

Spontaneous Intestinal Perforation (SIP)
Clinically similar to NEC, SIP is a focal, full-thickness perforation of the intestine that typically occurs in extremely low birth weight infants. Unlike NEC, it often lacks the preceding inflammatory signs of pneumatosis. The key imaging finding is pneumoperitoneum (free air in the abdomen) without other evidence of widespread enterocolitis.

Sepsis with Paralytic Ileus
Systemic infection in a neonate can lead to a functional bowel obstruction, or paralytic ileus. This presents with abdominal distension and feeding intolerance, mimicking early NEC. Imaging may show diffusely dilated, gas-filled loops of bowel but will lack specific signs like pneumatosis. Differentiating this from early NEC can be challenging and often relies on the evolving clinical and imaging picture.

Malrotation with Midgut Volvulus
This is a surgical emergency caused by the twisting of the intestine around the superior mesenteric artery, leading to bowel ischemia. While the classic presentation is bilious emesis in a neonate, it can mimic NEC. Imaging is focused on identifying the abnormal position of the bowel and duodenum, and signs of vascular compromise.

Why Are Ultrasound and Radiography the Recommended Initial Studies for Suspected NEC?

For an infant with suspected necrotizing enterocolitis, the ACR designates both Radiography abdomen and pelvis and US abdomen as Usually appropriate. In clinical practice, these studies are often used together to provide a comprehensive, low-risk initial evaluation.

Radiography abdomen and pelvis (Pediatric RRL: ☢☢☢ 0.3-3 mSv) is the traditional first-line modality. Its primary role is to rapidly assess for the most urgent complications. A two-view series (supine and a left lateral decubitus or cross-table lateral view) is essential.

  • Strengths: Radiography is unparalleled for its ability to detect pneumoperitoneum, the hallmark of bowel perforation, which requires immediate surgical consultation. It can also reveal nonspecific signs of ileus, such as dilated bowel loops, or more specific findings like a fixed, unchanging “sentinel loop” or pneumatosis intestinalis (which appears as bubbly or linear lucencies in the bowel wall).
  • Limitations: It is less sensitive than ultrasound for detecting early or subtle pneumatosis, assessing bowel wall thickness, and evaluating perfusion.

US abdomen (Pediatric RRL: O 0 mSv) is an increasingly vital tool in the initial workup, offering complementary information without using ionizing radiation.

  • Strengths: Ultrasound is more sensitive than radiography for detecting early signs of NEC. It can directly visualize bowel wall thickening, changes in wall echogenicity, and intramural gas (pneumatosis), which appears as bright, echogenic foci within the bowel wall. Critically, it can also assess for the presence or absence of peristalsis and evaluate bowel wall perfusion using color Doppler. It can also detect small amounts of free fluid that may precede perforation.
  • Limitations: Ultrasound is highly operator-dependent, and visualization can be limited by overlying bowel gas. It is less reliable than a decubitus radiograph for detecting pneumoperitoneum.

Why Alternative Studies Are Not Recommended Initially

  • CT abdomen and pelvis with IV contrast is rated Usually not appropriate. The high radiation dose (Pediatric RRL: ☢☢☢☢ 3-10 mSv) is a significant concern in this vulnerable population. CT is generally reserved for highly complex cases or when perforation is strongly suspected clinically but not confirmed on initial imaging.
  • Fluoroscopy contrast enema is also Usually not appropriate. Introducing contrast into a potentially compromised colon carries a high risk of perforation and is contraindicated in the workup for acute NEC.

In summary, the combination of abdominal radiography (to rule out perforation) and ultrasound (to assess for early signs of NEC) provides the most diagnostic yield with the lowest risk.

What’s the Next Step After Initial Imaging for Suspected NEC?

The results of the initial radiographs and ultrasound guide immediate management and subsequent steps in a rapidly evolving clinical situation.

  • Positive for Pneumoperitoneum: If free air is identified on radiography, this indicates bowel perforation. This is a surgical emergency. The next step is immediate consultation with pediatric surgery for consideration of an exploratory laparotomy. The infant should be stabilized with fluid resuscitation, broad-spectrum antibiotics, and gastric decompression.
  • Positive for NEC (Pneumatosis and/or Portal Venous Gas): If imaging confirms NEC but shows no evidence of perforation, the infant is diagnosed with medical NEC (Bell stage II). Management involves making the infant NPO (nothing by mouth), starting broad-spectrum IV antibiotics, providing IV fluids and parenteral nutrition, and decompressing the stomach with a nasogastric tube. The crucial next step is serial monitoring with abdominal radiographs every 6 to 8 hours to watch for progression or the development of perforation.
  • Negative or Equivocal Imaging: If the initial studies are normal or show only nonspecific ileus, but clinical suspicion for NEC remains high, the diagnosis is not ruled out. NEC is a dynamic disease. The next step is continued close clinical monitoring and serial imaging. A repeat abdominal radiograph and/or ultrasound in 6 to 12 hours may show evolving signs of the disease. Management is based on the infant’s clinical trajectory.

Common Pitfalls to Avoid in the Initial Workup of NEC

Navigating a suspected NEC case requires vigilance to avoid common diagnostic and management errors.

  • Relying on a Single Negative Radiograph: NEC is a progressive disease. A normal film at the onset of symptoms does not exclude the diagnosis. If clinical suspicion persists, serial imaging is mandatory.
  • Misinterpreting Supine-Only Films: A supine radiograph alone is insensitive for detecting small amounts of free air. A left lateral decubitus or cross-table lateral view is essential to allow free air to rise over the liver, making it visible.
  • Delaying Surgical Consultation: Any sign of perforation (pneumoperitoneum) or clinical deterioration in an infant with confirmed NEC (e.g., worsening acidosis, thrombocytopenia, abdominal wall erythema) warrants immediate surgical consultation.
  • Overlooking Alternative Diagnoses: If the imaging findings are atypical for NEC, reconsider other surgical emergencies like malrotation with volvulus, especially if bilious emesis is a prominent feature.

If the clinical picture is deteriorating despite negative or equivocal imaging, escalate care by involving senior clinicians and pediatric surgery early.

Related ACR Topics and Tools

For a comprehensive understanding of imaging for pediatric abdominal pain and related technical standards, the following resources are valuable. For breadth across all scenarios in Abdominal Pain-Child, see our parent guide: Abdominal Pain-Child: ACR Appropriateness Decoded.

Frequently Asked Questions

Why are both radiography and ultrasound considered ‘Usually Appropriate’ for suspected NEC?

They serve complementary roles. Abdominal radiography is the best initial test to quickly and reliably detect pneumoperitoneum (bowel perforation), a surgical emergency. Abdominal ultrasound is more sensitive for detecting early signs of NEC, such as gas within the bowel wall (pneumatosis), bowel wall thickening, and changes in blood flow, all without using ionizing radiation. Using both provides a comprehensive initial assessment.

If the initial abdominal radiograph is normal, can I rule out necrotizing enterocolitis?

No. NEC is a dynamic disease process, and initial radiographs can be normal. If clinical suspicion remains high (e.g., persistent abdominal distension, bloody stools, or clinical instability), serial imaging with repeat radiographs and/or ultrasound every 6-12 hours is crucial to monitor for developing signs of the disease.

Is a CT scan ever used to diagnose NEC in an infant?

Rarely. The American College of Radiology rates CT as ‘Usually not appropriate’ for the initial diagnosis of NEC due to the high radiation dose in a neonate. CT may be considered in very specific, complex situations, such as evaluating for an abscess or when perforation is suspected but not visible on plain films, but it is not a first-line tool.

What is the significance of portal venous gas on imaging?

Portal venous gas, which appears as linear branching lucencies over the liver on radiograph or echogenic foci in the portal vein on ultrasound, is a specific but less common sign of advanced necrotizing enterocolitis. It indicates that gas from the damaged bowel wall has entered the portal venous system. It is associated with more severe disease and a higher mortality rate.

Should I order a contrast study like an upper GI series or contrast enema for suspected NEC?

No. A contrast enema is rated ‘Usually not appropriate’ and is contraindicated in acute NEC due to the high risk of perforating the inflamed, friable bowel. An upper GI series is not used to diagnose NEC but may be considered if the primary differential diagnosis shifts to malrotation with midgut volvulus, and the infant is stable enough for the procedure.

Reviewed by Pouyan Golshani, MD, Interventional Radiologist — May 30, 2026
