Pediatric Imaging

What Is the Best Initial Imaging for a Child with Sickle Cell Disease and Chest Pain?

·
What Is the Best Initial Imaging for a Child with Sickle Cell Disease and Chest Pain?

A 9-year-old with a known history of sickle cell disease (HbSS) presents to the emergency department with a two-day history of escalating chest pain, cough, and a low-grade fever. His oxygen saturation is 93% on room air. You are concerned about Acute Chest Syndrome (ACS), a life-threatening complication, and need to decide on the most appropriate initial imaging study to guide immediate management. This article details the American College of Radiology (ACR) evidence-based workflow for this specific clinical question. For a child with chest pain and a history of sickle cell disease, the ACR designates Radiography chest as Usually Appropriate.

Who Fits This Clinical Scenario for Chest Pain in a Child with Sickle Cell Disease?

This guidance applies specifically to the initial imaging workup for a child (from infancy through adolescence) with a known diagnosis of sickle cell disease who presents with acute or subacute chest pain. The patient may have associated symptoms like fever, cough, tachypnea, or hypoxia. The key context is that this is the first imaging study being ordered for this specific presentation to evaluate for common and life-threatening intrathoracic complications.

This workflow is distinct from other pediatric chest pain scenarios. It is crucial to differentiate this presentation from:

  • Chest wall pain: If the pain is highly localized, reproducible with palpation, and lacks systemic signs like fever or hypoxia, it may fit the chest wall pain variant, which has a different diagnostic focus.
  • Primary cardiac concern: If the patient has a known cardiomyopathy or presents with clear signs of heart failure (e.g., gallop, significant edema, jugular venous distention), the workup may align more closely with the known or suspected cardiac disease variant.
  • High suspicion for pulmonary embolism (PE): While PE can occur in sickle cell disease, if it is the leading diagnosis based on specific clinical signs (e.g., pleuritic pain, hemoptysis, unexplained severe hypoxia), the dedicated suspected PE workflow would be more appropriate, as it often involves advanced imaging like CT angiography.

What Diagnoses Are You Working Up in This Scenario?

In a child with sickle cell disease and chest pain, the differential diagnosis is focused on serious complications of the underlying condition. The initial imaging choice is designed to rapidly assess for the most common and urgent possibilities.

Acute Chest Syndrome (ACS) is the most critical diagnosis to establish or exclude. It is a leading cause of mortality in patients with sickle cell disease. The formal definition requires a new pulmonary infiltrate on a chest radiograph, combined with clinical signs such as fever, cough, wheezing, tachypnea, or chest pain. The underlying cause can be infection, pulmonary fat embolism from bone marrow infarction, or in situ sickling and vaso-occlusion within the pulmonary vasculature. Identifying an infiltrate is a cornerstone of diagnosis and triggers aggressive management.

Pneumonia is a frequent trigger for ACS and can be clinically indistinguishable from it on presentation. Differentiating a simple community-acquired pneumonia from the broader inflammatory cascade of ACS can be difficult, but identifying the pulmonary infiltrate with radiography is the essential first step for both conditions, guiding antibiotic therapy and supportive care.

Vaso-occlusive Crisis (VOC) of the Ribs or Sternum can cause severe chest pain that mimics intrathoracic pathology. Sickling within the bone marrow of the thoracic cage leads to infarction and intense pain. In this case, the chest radiograph is valuable for its negative predictive power; a clear lung field helps point the clinical team toward a bony VOC as the pain generator, which has a different management pathway than ACS.

Less common but consequential considerations include pulmonary embolism and pericarditis. While a chest radiograph is not the definitive test for either, it can reveal ancillary findings like a pleural effusion, atelectasis, or an enlarged cardiac silhouette that may heighten suspicion and guide further, more specific testing.

Why Is a Chest Radiograph the Recommended Initial Study for This Presentation?

The ACR designates a chest radiograph as Usually Appropriate because it is the most direct, rapid, and lowest-risk method to evaluate for Acute Chest Syndrome, the primary concern in this clinical scenario. Its value lies in its ability to confirm or exclude the presence of a new pulmonary infiltrate, a key criterion for the diagnosis.

A two-view (posteroanterior/anteroposterior and lateral) chest radiograph is highly effective for identifying the parenchymal opacities, pleural effusions, or areas of atelectasis characteristic of ACS or pneumonia. Its widespread availability and speed are critical in an emergency setting where timely diagnosis directly impacts treatment decisions like oxygen administration, incentive spirometry, antibiotic selection, and potential exchange transfusion.

In contrast, other more advanced imaging modalities are rated as Usually not appropriate for the initial workup:

  • CT chest with IV contrast: While more sensitive for subtle infiltrates or alternative diagnoses like pulmonary embolism, CT is not the appropriate first step. It exposes the child to substantially more ionizing radiation (pediatric RRL ☢☢☢☢ 3-10 mSv) compared to a radiograph (pediatric RRL ☢ <0.03 mSv). This is a critical consideration in a patient population that will likely undergo numerous imaging studies over their lifetime. CT is reserved for situations where the radiograph is inconclusive, the patient is deteriorating despite treatment, or there is a high clinical suspicion for a complication like PE or abscess.
  • US echocardiography transthoracic resting: This study is also rated Usually not appropriate as an initial test for this presentation. Its role is to assess cardiac structure and function, not the lung parenchyma. It would be considered later in the workup if there are signs of heart failure, a new murmur, or suspicion of pericardial effusion, but it does not address the primary question of ACS.

When ordering, it is crucial to request both frontal and lateral views. Most importantly, comparison with any available prior chest radiographs is essential. The diagnosis of ACS hinges on identifying a new or evolving infiltrate, which can be missed without a baseline for comparison.

What’s Next After the Chest Radiograph? Downstream Workflow

The results of the initial chest radiograph create a clear decision-making branch point for managing a child with sickle cell disease and chest pain.

If the radiograph is positive for a new infiltrate: The diagnosis of Acute Chest Syndrome is confirmed. This triggers immediate and aggressive management, including supplemental oxygen to maintain saturation, broad-spectrum antibiotics covering typical and atypical organisms, pain control, and hydration. The clinical team, often in consultation with a hematologist, will decide on the need for simple or exchange blood transfusion based on the severity of respiratory distress and hypoxia.

If the radiograph is negative (clear lung fields): ACS is less likely at this moment, but it is not entirely ruled out, as radiographic changes can lag behind clinical symptoms by 24-48 hours. The focus of the workup shifts. The leading diagnosis becomes a vaso-occlusive crisis (VOC) involving the ribs, sternum, or spine. Management would focus on aggressive pain control and hydration. However, the patient requires close observation with a low threshold for a repeat chest radiograph in 12-24 hours if respiratory symptoms worsen or fail to improve, as a delayed-onset ACS is a known phenomenon.

If the radiograph is indeterminate or shows non-specific findings: Findings like minor atelectasis or a small pleural effusion can be ambiguous. In this case, the clinical picture dictates the next step. If the patient is clinically stable, a period of observation with supportive care and a follow-up radiograph is often appropriate. If the patient is deteriorating or has severe hypoxia despite a non-diagnostic radiograph, escalation to CT angiography of the chest may be warranted to evaluate for pulmonary embolism or a subtle infiltrate not visible on the plain film.

Pitfalls to Avoid (and When to Get Help)

Navigating this scenario requires vigilance to avoid common diagnostic and management errors.

  • Pitfall 1: Over-relying on a single negative radiograph. A clear chest X-ray at presentation does not exclude developing ACS. Always maintain a high index of suspicion and repeat the imaging if the patient’s respiratory status worsens.
  • Pitfall 2: Forgetting to compare with prior images. A subtle new opacity can be easily missed without a baseline. Chronic changes related to sickle cell lung disease are common, and only a comparison can reliably identify an acute process.
  • Pitfall 3: Delaying antibiotics. Given the significant overlap between pneumonia and ACS, and the role of infection as a trigger, broad-spectrum antibiotics should be started empirically as soon as ACS is suspected, even before radiographic confirmation.

If the patient exhibits severe respiratory distress, rapidly declining oxygen saturation, or neurologic changes, this constitutes a medical emergency. Escalate immediately by involving a pediatric critical care specialist and a hematologist for consideration of exchange transfusion and intensive care unit-level support.

Related ACR Topics and Tools

For a comprehensive overview of imaging for all pediatric chest pain presentations, this depth piece is best used alongside its parent topic article. The following resources provide additional context for evidence-based imaging decisions.

Frequently Asked Questions

Why not start with a CT scan to be more sensitive for Acute Chest Syndrome?

A CT scan is rated ‘Usually not appropriate’ as the initial imaging study primarily due to the significantly higher radiation dose compared to a chest radiograph. In a pediatric patient with a chronic condition requiring lifelong medical care and likely multiple future imaging studies, minimizing cumulative radiation exposure is a key principle (ALARA – As Low As Reasonably Achievable). A chest radiograph is sufficient to diagnose the vast majority of ACS cases and is the established standard of care.

What if the chest radiograph is normal but my clinical suspicion for ACS remains very high?

If the initial radiograph is clear but the child has significant respiratory symptoms (tachypnea, hypoxia), the diagnosis is not excluded. Radiographic findings of ACS can lag clinical symptoms by 24-48 hours. The standard approach is to admit the patient for observation, provide supportive care (oxygen, fluids, pain control), and plan for a repeat chest radiograph in 12-24 hours or sooner if their condition worsens.

Does the type of sickle cell disease (e.g., HbSS vs. HbSC) change the initial imaging choice?

No, the initial imaging recommendation for a chest radiograph remains the same regardless of the specific sickle cell genotype. While the frequency and severity of complications like ACS can vary between genotypes (being most common and severe in HbSS), the diagnostic approach to a patient presenting with chest pain and suspected ACS is identical.

Is a portable anteroposterior (AP) radiograph sufficient if the child is too sick to go to the radiology department?

Yes, a portable AP chest radiograph is an acceptable alternative if the patient is clinically unstable. While a two-view study (PA and lateral) performed in the radiology suite is technically superior for detecting subtle infiltrates and pleural effusions, the immediate diagnostic need in a critically ill child outweighs the benefits of a technically perfect study. The priority is to obtain a diagnostic image as quickly and safely as possible.

When should I consider a ventilation/perfusion (V/Q) scan in this scenario?

A V/Q scan is primarily used to diagnose pulmonary embolism (PE). It is not a first-line test for suspected ACS. It would only be considered if PE is the leading diagnosis and a CT pulmonary angiogram is contraindicated (e.g., due to severe renal dysfunction or a contrast allergy). For the initial workup of undifferentiated chest pain in a child with sickle cell disease, a chest radiograph is the correct starting point.

Reviewed by Pouyan Golshani, MD, Interventional Radiologist — May 30, 2026
