It’s 11 p.m. in the emergency department, and you’re evaluating a patient with new-onset, substernal chest pain. The initial EKG is non-specific, and the first troponin is pending. The clinical picture is concerning but not definitive for acute coronary syndrome (ACS). You need to decide on the next diagnostic step. Do you order a coronary CT angiogram (CCTA) to rule out obstructive disease, a stress test to assess for ischemia, or admit for observation and serial biomarkers? This common clinical dilemma requires a careful balance of diagnostic yield, radiation exposure, and resource utilization. The American College of Radiology (ACR) Appropriateness Criteria provide an evidence-based framework to guide this decision, helping you select the right imaging test for the right patient at the right time. This article breaks down the ACR guidelines for chest pain with possible ACS, providing clear, scannable recommendations for your next case.

What Does ACR Chest Pain-Possible Acute Coronary Syndrome Cover?

The ACR Appropriateness Criteria for “Chest Pain-Possible Acute Coronary Syndrome” focus specifically on patients presenting with symptoms suggestive of ACS where the diagnosis is uncertain after initial clinical evaluation, including history, physical exam, EKG, and cardiac biomarkers. The guidelines are stratified based on the pre-test probability of ACS—low-to-intermediate versus high—as this is the critical factor driving the imaging strategy.

These criteria are intended for initial, non-invasive diagnostic imaging. They do not apply to patients with a confirmed diagnosis of ST-elevation myocardial infarction (STEMI), who require immediate cardiac catheterization, or to patients with known coronary artery disease undergoing routine surveillance. Furthermore, while there is overlap in symptoms, these specific guidelines are not primarily designed for the workup of other causes of chest pain, such as suspected pulmonary embolism, aortic dissection, or pericarditis, which have their own dedicated ACR criteria. The primary goal here is to risk-stratify and diagnose or rule out ACS as the cause of the patient’s acute symptoms.

What Imaging Should I Order for Chest Pain-Possible Acute Coronary Syndrome? Recommendations by Clinical Scenario

The optimal imaging pathway for possible ACS depends heavily on the patient’s pre-test probability. The ACR provides distinct recommendations for low-to-intermediate and high-probability scenarios.

For a patient with chest pain and a low to intermediate probability for acute coronary syndrome, the goal is often to non-invasively rule out significant coronary artery disease. In this setting, several options are rated as Usually Appropriate. A Coronary CTA with IV contrast (CCTA) is a powerful tool with a high negative predictive value for excluding obstructive coronary stenosis. Functional testing is also highly valued; both Transthoracic Stress Echocardiography and SPECT or SPECT/CT Myocardial Perfusion Imaging (MPI) rest and stress are excellent choices to assess for inducible ischemia. A simple Chest Radiograph is also usually appropriate to evaluate for alternative causes of chest pain, such as pneumonia or pneumothorax.

For a patient with chest pain and a high probability for acute coronary syndrome, the management strategy shifts from non-invasive rule-out to definitive diagnosis and potential intervention. The ACR rates Coronary Arteriography as Usually Appropriate. This invasive procedure is the gold standard for diagnosing and treating obstructive coronary disease. A Chest Radiograph remains usually appropriate to assess for complications like heart failure or other etiologies. In this high-risk population, non-invasive tests like CCTA and stress imaging are downgraded to May Be Appropriate, as a negative or equivocal result may not be sufficient to rule out ACS, potentially delaying necessary invasive management.

ACR Imaging Recommendations Table

Adult vs. Pediatric Chest Pain-Possible Acute Coronary Syndrome Imaging: Radiation Dose Tradeoffs

While acute coronary syndrome is a leading cause of morbidity and mortality in adults, it is exceedingly rare in the pediatric population. Chest pain in children and adolescents is most often musculoskeletal, psychogenic, or related to respiratory conditions. The pre-test probability of ACS is therefore near zero in most pediatric cases, and the differential diagnosis is substantially different.

The ACR guidelines reflect this by providing pediatric-specific Relative Radiation Level (RRL) estimates, which are often in a higher tier than their adult counterparts for the same CT or nuclear medicine study. This is due to the increased radiosensitivity of developing tissues and the longer potential lifespan over which radiation-related risks could manifest. The principle of ALARA (As Low As Reasonably Achievable) is paramount. For this reason, non-ionizing modalities like echocardiography and MRI are strongly preferred when cardiac imaging is necessary in children. High-dose radiation studies like SPECT MPI or CCTA should be reserved for rare cases with a very high clinical suspicion for specific conditions, such as congenital coronary anomalies (e.g., ALCAPA) or Kawasaki disease with coronary aneurysms, after consultation with a pediatric cardiologist.

Imaging Protocol Details for Chest Pain-Possible Acute Coronary Syndrome

Once you’ve decided on the right study based on the clinical scenario and ACR appropriateness ratings, the specific imaging protocol is critical for diagnostic accuracy. A well-designed protocol ensures that the images acquired can definitively answer the clinical question, while a suboptimal one can lead to non-diagnostic results and repeat imaging. Our protocol guides cover key considerations like patient preparation, contrast media administration, and technical parameters for many of the studies recommended above.

• CT Chest/Abdomen/Pelvis with IV Contrast

Tools to Help You Order the Right Study

Navigating imaging guidelines and protocols can be complex, especially under the time pressure of acute clinical care. GigHz offers a suite of free reference tools designed to support evidence-based decision-making at the point of care.

The ACR Appropriateness Criteria Lookup provides a searchable interface for the full library of ACR guidelines, allowing you to find recommendations for hundreds of clinical scenarios beyond chest pain. When you need to understand the technical details of a specific scan, the Imaging Protocol Library offers concise, practical guides. For discussions about radiation exposure with patients and for tracking cumulative dose, the Radiation Dose Calculator is a valuable resource for translating RRLs into understandable terms.

Why is Coronary CTA rated ‘Usually Appropriate’ for low-to-intermediate risk but only ‘May Be Appropriate’ for high-risk patients?

In low-to-intermediate risk patients, the primary goal is often to confidently rule out coronary artery disease. Coronary CT Angiography (CCTA) has a very high negative predictive value, meaning a normal CCTA makes significant obstructive disease highly unlikely. This allows for safe patient discharge from the emergency department. In high-risk patients, the pre-test probability of disease is high, and the clinical question shifts from ruling out disease to confirming it and planning for intervention. An invasive coronary angiogram is the gold standard for this purpose, as it provides definitive diagnosis and allows for immediate percutaneous coronary intervention (PCI) if needed. A CCTA in this setting could delay definitive care.

What is the role of a plain chest radiograph in working up possible ACS?

A chest radiograph is rated ‘Usually Appropriate’ in both low/intermediate and high-risk scenarios. While it cannot diagnose coronary artery stenosis, it is invaluable for evaluating for alternative or contributing causes of chest pain. It can reveal conditions like pneumonia, pneumothorax, aortic dissection (e.g., widened mediastinum), pericardial effusion, or signs of heart failure (e.g., pulmonary edema, cardiomegaly), which are critical to identify in the acute setting.

When should I choose a functional stress test over an anatomic test like CCTA?

The choice between a functional test (like stress echo or SPECT MPI) and an anatomic test (CCTA) depends on the specific clinical question and patient factors. CCTA is excellent for assessing coronary anatomy and ruling out stenosis, particularly in younger patients with fewer comorbidities. Functional tests are designed to determine if a known or suspected stenosis is causing myocardial ischemia (i.e., if it is hemodynamically significant). They are often preferred in patients with known non-obstructive disease, or when the primary question is about the physiologic consequence of a potential blockage rather than just its presence.

Why are so many MRI procedures listed as ‘May be appropriate’ or ‘Usually not appropriate’?

Cardiac MRI (CMR) is a powerful, versatile imaging modality that provides excellent assessment of cardiac function, morphology, and tissue characterization (e.g., identifying scar from a prior infarct) without using ionizing radiation. However, in the acute setting of possible ACS, its primary limitations are availability, scan time, and patient stability. CMR scans can be lengthy and require a patient to lie still, which may not be feasible for an unstable patient with ongoing chest pain. Therefore, while it has a definite role in subacute or post-ACS evaluation, it is often not the first-line test in the initial emergency workup, leading to its ‘May be appropriate’ or ‘Usually not appropriate’ ratings in this specific context.

What does the ‘(Disagreement)’ tag next to an ACR rating mean?

The ‘(Disagreement)’ tag indicates that while the expert panel reached a consensus on the final appropriateness rating (e.g., ‘May be appropriate’), there was a notable lack of uniformity in the voting during the rating process. This signifies that there is a legitimate diversity of opinion among experts regarding the value or role of that specific procedure for the given clinical scenario. It suggests that the choice to use this test may be more dependent on local expertise, available technology, and specific patient factors compared to a procedure with a unanimous rating.

Reviewed by Pouyan Golshani, MD, Interventional Radiologist — May 12, 2026
