It’s the middle of a busy clinic day. A 55-year-old patient presents with intermittent, exertional chest pain that has been occurring for several months. The electrocardiogram (ECG) is normal and cardiac enzymes are negative. You’ve determined a noncardiac cause is unlikely, and your pre-test probability assessment places the patient in the low to intermediate risk category for coronary artery disease (CAD). The next step is choosing the right initial imaging study. Do you order a stress echocardiogram, a coronary computed tomography angiography (CTA), or a nuclear stress test? Each has distinct advantages, radiation profiles, and diagnostic capabilities. This guide decodes the American College of Radiology (ACR) Appropriateness Criteria to help you select the most effective and safe imaging pathway for this common clinical challenge.

What Does ACR Chronic Chest Pain-Noncardiac Etiology Unlikely: Low to Intermediate Probability of Coronary Artery Disease Cover?

This ACR guideline focuses on a specific and frequently encountered patient population: individuals presenting with stable, chronic chest pain where the clinical suspicion for significant obstructive coronary artery disease is low to intermediate. The key elements defining this scope include:

• Chronic Chest Pain: The symptoms are not acute. This guideline does not apply to patients presenting to the emergency department with acute chest pain suspicious for an acute coronary syndrome.
• Noncardiac Etiology Unlikely: The clinical evaluation (history, physical exam) does not point strongly toward a gastrointestinal, musculoskeletal, or pulmonary cause of the pain.
• Low to Intermediate Probability of CAD: Based on risk factors (age, sex, symptom character, diabetes, hypertension, hyperlipidemia, smoking history), the pre-test probability of obstructive CAD is not high. This guideline is intended for diagnostic workup, not for evaluating patients with known, established CAD or those with high-risk features who may be better served by invasive coronary angiography.

This framework is designed to guide the initial, non-invasive imaging choice to either rule out significant CAD or identify disease that requires further management, balancing diagnostic yield with patient safety and resource utilization.

What Imaging Should I Order for Chronic Chest Pain-Noncardiac Etiology Unlikely: Low to Intermediate Probability of Coronary Artery Disease? Recommendations by Clinical Scenario

For the initial imaging workup of a patient with chronic chest pain and a low to intermediate probability of coronary artery disease, the ACR provides several excellent first-line options, differentiating between anatomical and functional testing.

Usually Appropriate Options:
The ACR rates a number of studies as “Usually Appropriate,” giving clinicians flexibility based on local expertise, equipment availability, and patient-specific factors. These include both functional stress tests and an anatomic test. Coronary CTA with IV contrast is an excellent anatomic test that directly visualizes the coronary arteries to assess for stenosis. It has a very high negative predictive value, making it ideal for ruling out obstructive CAD in this population. Functional tests rated as “Usually Appropriate” include stress transthoracic echocardiography, cardiac MRI with vasodilator stress perfusion, and several nuclear cardiology options like SPECT or SPECT/CT MPI (stress only or rest/stress) and Rb-82 PET/CT MPI (rest/stress). These studies assess for ischemia (a downstream effect of stenosis) by evaluating myocardial perfusion or wall motion abnormalities under stress. The choice between them often depends on factors like body habitus, ability to exercise, and the need to avoid ionizing radiation.

May Be Appropriate Options:
Several other studies are rated as “May Be Appropriate.” These are generally not considered first-line choices but can be valuable in specific circumstances. A resting transthoracic echocardiogram can assess for structural heart disease or regional wall motion abnormalities suggestive of prior infarction but does not assess for ischemia. A CT for coronary calcium scoring can re-stratify risk but does not show luminal stenosis. A standard CT chest with IV contrast is not a dedicated cardiac study and is generally used to evaluate for other thoracic pathology like pulmonary embolism or aortic dissection, which are not the primary concern here. Various cardiac MRI protocols without stress may also be appropriate if the primary question is about function or morphology rather than ischemia.

Usually Not Appropriate Options:
Finally, the ACR designates some tests as “Usually Not Appropriate” for this initial evaluation. Invasive coronary arteriography is typically reserved for patients with high-risk features or those who have had positive or high-risk non-invasive tests. Standard non-gated chest CT scans (with or without contrast) are not suitable for evaluating coronary anatomy. A rest-only nuclear perfusion scan (SPECT or SPECT/CT MPI rest only) is also not appropriate, as it cannot induce or detect ischemia, which is the central question in a patient with exertional symptoms.

ACR Imaging Recommendations Table

Adult vs. Pediatric Chronic Chest Pain-Noncardiac Etiology Unlikely: Low to Intermediate Probability of Coronary Artery Disease Imaging: Radiation Dose Tradeoffs

While chronic chest pain suspicious for coronary disease is predominantly an adult presentation, similar symptoms in pediatric patients require careful consideration, particularly regarding radiation exposure. The principle of ALARA (As Low As Reasonably Achievable) is paramount. For this reason, non-ionizing modalities like stress echocardiography and cardiac MRI are strongly preferred as initial tests in younger patients when clinically appropriate. The ACR guidelines reflect this by providing pediatric-specific Relative Radiation Levels (RRLs). For instance, a coronary CTA carries an RRL of ☢ ☢ ☢ (1-10 mSv) in adults but a higher category of ☢ ☢ ☢ ☢ (3-10 mSv) in children, reflecting greater radiosensitivity of developing tissues. Similarly, a rest/stress SPECT/CT MPI is rated ☢ ☢ ☢ ☢ (10-30 mSv) for adults but falls into the highest category, ☢ ☢ ☢ ☢ ☢ (10-30 mSv), for pediatrics. This underscores the need to justify any radiation-based study in children and to exhaust non-ionizing alternatives first. Several nuclear medicine studies, such as stress-only SPECT and PET/CT, lack a pediatric RRL, indicating they are less commonly performed or validated for this indication in children.

Imaging Protocol Details for Chronic Chest Pain-Noncardiac Etiology Unlikely: Low to Intermediate Probability of Coronary Artery Disease

Once you’ve decided on the right study, the specific imaging protocol is critical for diagnostic accuracy. A coronary CTA, for example, requires precise timing of contrast, ECG gating to minimize cardiac motion artifact, and often beta-blockers to control heart rate. A stress echocardiogram protocol must achieve an adequate heart rate response to be diagnostically valid. While this article summarizes the ACR’s recommendations on *what* to order, the *how* is equally important. For detailed guidance on technique, contrast administration, patient preparation, and interpretation principles for these and other imaging studies, the GigHz Imaging Protocol Library is a valuable resource for clinicians and trainees.

Tools to Help You Order the Right Study

Navigating imaging guidelines can be complex, but several tools can streamline the process of selecting the most appropriate study and communicating with patients. These resources are designed to integrate evidence-based medicine into daily clinical workflow.

For scenarios beyond this specific topic, the ACR Appropriateness Criteria Lookup provides a comprehensive, searchable interface to find the official ACR recommendations for thousands of clinical variants. To ensure the selected study is performed correctly, the Imaging Protocol Library offers detailed, step-by-step protocols for a wide range of CT, MRI, and ultrasound examinations. When discussing studies that involve ionizing radiation, the Radiation Dose Calculator is an essential tool for estimating cumulative exposure and facilitating informed conversations with patients about the risks and benefits of imaging.

Why is coronary CTA rated ‘Usually Appropriate’ for low-to-intermediate risk patients?

Coronary Computed Tomography Angiography (CTA) is highly effective in this population due to its excellent negative predictive value. For a patient with a low to intermediate pre-test probability of disease, a negative coronary CTA (showing no significant plaque or stenosis) very reliably rules out obstructive coronary artery disease as the cause of their symptoms. This can prevent further unnecessary testing and provide reassurance to both the clinician and the patient. It provides direct anatomical information, which is a different approach than the functional information provided by stress tests.

What is the difference between a stress-only and a rest/stress nuclear perfusion study?

A stress-only myocardial perfusion imaging (MPI) study involves injecting a radiotracer only at peak stress (exercise or pharmacologic) to see if all parts of the heart muscle receive adequate blood flow. If the stress images are normal, the test is complete. A rest/stress study involves two sets of images: one at rest and one at stress. This allows for direct comparison to see if a perfusion defect is new with stress (indicating ischemia) or fixed (indicating a prior heart attack/scar). For initial diagnosis in a low-risk patient, a stress-only protocol can be sufficient and significantly reduces the patient’s radiation dose.

When should I choose a stress echocardiogram over a nuclear stress test?

A stress echocardiogram is an excellent choice that involves no ionizing radiation. It is often preferred in younger patients, pregnant women, or anyone with concerns about radiation exposure. It assesses for ischemia by looking for stress-induced wall motion abnormalities. A nuclear stress test may be preferred in patients with poor acoustic windows (e.g., due to obesity or lung disease) that would make an echocardiogram difficult to interpret, or when a more quantitative assessment of perfusion is desired.

Why is invasive coronary arteriography ‘Usually Not Appropriate’ as an initial test?

Invasive coronary arteriography (cardiac catheterization) is the gold standard for diagnosing coronary artery disease, but it is an invasive procedure with a small but real risk of complications, including bleeding, stroke, and vessel injury. For patients with a low to intermediate probability of having significant disease, the risks of the invasive procedure generally outweigh the potential benefits. The ACR recommends starting with non-invasive tests to stratify risk and identify which patients are most likely to benefit from an invasive approach.

What is the role of a Coronary Artery Calcium (CAC) score in this setting?

A CT for Coronary Artery Calcium (CAC) scoring is rated as ‘May be appropriate’. A CAC score is a measure of the total amount of calcified plaque in the coronary arteries. While a score of zero is associated with a very low risk of future cardiac events, the test does not show non-calcified plaque or the degree of luminal stenosis. Therefore, it is primarily a risk stratification tool, not a direct test for obstructive disease causing symptoms. It can be useful in refining a patient’s risk profile, but a functional test or a coronary CTA is typically better for evaluating the direct cause of chest pain.

Reviewed by Pouyan Golshani, MD, Interventional Radiologist — May 12, 2026
