A patient presents with dyspnea, and the initial workup has confidently excluded acute coronary ischemia. The ECG is non-ischemic, and troponins are negative. Yet, the clinical suspicion for a cardiac etiology remains high. Is this new-onset heart failure from valvular disease, a manifestation of pericarditis, or an underlying arrhythmia causing hemodynamic compromise? Choosing the next diagnostic step requires navigating a complex decision tree of imaging modalities, each with its own strengths, weaknesses, and radiation exposure profile. This guide decodes the American College of Radiology (ACR) Appropriateness Criteria to clarify which imaging studies are most valuable in this common clinical scenario.

What Does ACR Dyspnea-Suspected Cardiac Origin (Ischemia Already Excluded) Cover?

This ACR guideline focuses specifically on patients presenting with shortness of breath where a cardiac cause is suspected, but acute myocardial ischemia has already been reasonably ruled out. The criteria are designed to help clinicians differentiate among several non-ischemic cardiac conditions that can cause dyspnea. The primary clinical questions addressed include the evaluation for:

• Valvular heart disease
• Cardiac arrhythmia
• Pericardial disease (e.g., pericarditis, effusion, or constriction)

This topic does not apply to patients with suspected acute coronary syndrome, pulmonary embolism, or primary pulmonary causes of dyspnea (like pneumonia or COPD exacerbation). The core assumption is that the immediate life-threat of myocardial infarction has been addressed, allowing for a more deliberate workup of other potential cardiac pathologies. It provides a framework for selecting the most appropriate initial imaging test to evaluate cardiac structure and function in this specific post-ischemia-workup context.

What Imaging Should I Order for Dyspnea-Suspected Cardiac Origin (Ischemia Already Excluded)? Recommendations by Clinical Scenario

The ACR provides specific recommendations based on the most likely underlying pathology after initial clinical assessment. The choice of imaging hinges on whether the primary suspicion is valvular, arrhythmic, or pericardial disease.

For a patient with dyspnea due to suspected valvular heart disease, the ACR rates a resting transthoracic echocardiogram (TTE) as Usually appropriate. This non-invasive, radiation-free ultrasound is the cornerstone for assessing valve morphology, stenosis, regurgitation, and overall ventricular function. A chest radiograph is also rated Usually appropriate to evaluate for cardiomegaly, pulmonary edema, or other concomitant findings. More advanced tests like transesophageal echocardiography (TEE), stress echocardiography, or cardiac MRI May be appropriate if initial TTE is non-diagnostic or further characterization is needed.

When the clinical picture suggests dyspnea due to a suspected cardiac arrhythmia, a resting TTE is again rated Usually appropriate to assess for structural heart disease that could be the substrate for the arrhythmia. In this scenario, a cardiac MRI (with and without contrast) is also considered Usually appropriate, as it offers superior tissue characterization to identify potential causes like scar or infiltrative cardiomyopathy. Interestingly, the panel notes disagreement on the utility of a chest radiograph, rating it May be appropriate (Disagreement). Cardiac CT and FDG-PET/CT May be appropriate in select cases.

If dyspnea is due to suspected pericardial disease, the list of first-line imaging options expands. Four modalities are rated Usually appropriate: resting TTE, chest radiography, cardiac MRI (with and without contrast), and cardiac CT (with contrast). TTE is excellent for detecting pericardial effusions, while chest X-ray may show an enlarged cardiac silhouette. Cardiac MRI and CT provide superior anatomical detail of the pericardium itself, which is critical for diagnosing constrictive pericarditis or pericardial masses. The choice between them often depends on local expertise and specific clinical questions.

ACR Imaging Recommendations Table

Adult vs. Pediatric Dyspnea-Suspected Cardiac Origin (Ischemia Already Excluded) Imaging: Radiation Dose Tradeoffs

Evaluating dyspnea of suspected cardiac origin in pediatric patients requires heightened attention to the principle of As Low As Reasonably Achievable (ALARA) regarding radiation exposure. Children are more radiosensitive than adults, and their longer life expectancy provides more time for potential stochastic effects of radiation to manifest. Consequently, non-ionizing modalities are strongly preferred as first-line options.

Transthoracic echocardiography and cardiac MRI, both of which have a relative radiation level of zero, are invaluable in the pediatric population. The ACR guidelines reflect this by consistently rating TTE as ‘Usually appropriate’ across scenarios. While ionizing studies like chest radiography and CT are sometimes necessary, the pediatric relative radiation levels (RRL) are often lower than their adult counterparts (e.g., ☢ <0.03 mSv for a pediatric chest X-ray vs. <0.1 mSv for an adult). This is achieved through size-specific protocols and dose modulation techniques. When a CT is deemed necessary, the potential diagnostic benefit must be carefully weighed against the cumulative radiation dose, and every effort should be made to use the lowest possible dose that still provides diagnostic-quality images.

Imaging Protocol Details for Dyspnea-Suspected Cardiac Origin (Ischemia Already Excluded)

Once you have decided on the right study, the specific imaging protocol is critical for ensuring diagnostic quality. While this article focuses on selecting the appropriate modality, the technical execution—from patient preparation to contrast timing and sequence selection—determines the value of the resulting images. Our comprehensive Imaging Protocol Library provides detailed, step-by-step guides for many of the modalities discussed in these ACR criteria, including Cardiac MRI and various CT applications. These resources are designed to help clinical teams standardize techniques and optimize imaging for specific diagnostic questions.

Tools to Help You Order the Right Study

Navigating imaging guidelines during a busy clinical shift can be challenging. To streamline the process of evidence-based ordering, GigHz provides several resources for physicians and trainees.

The ACR Appropriateness Criteria Lookup tool allows you to quickly search the full ACR guidelines for thousands of clinical scenarios beyond dyspnea, ensuring you can find the right test for any patient presentation. For detailed technical specifications on how to perform a study, the Imaging Protocol Library offers step-by-step guides for a wide range of imaging procedures. Finally, to help in discussions with patients about radiation exposure and to track cumulative dose, the Radiation Dose Calculator provides a simple way to estimate and explain effective dose from common imaging studies.

Why is Transthoracic Echocardiography (TTE) so consistently rated ‘Usually appropriate’?

Transthoracic echocardiography is consistently rated ‘Usually appropriate’ because it is a non-invasive, widely available, and cost-effective imaging modality that uses no ionizing radiation. It provides a wealth of real-time information about cardiac structure and function, including ventricular size and systolic function, wall motion abnormalities, valvular morphology and function, and the presence of a pericardial effusion. For the initial evaluation of non-ischemic cardiac dyspnea, it is often the single most valuable diagnostic test.

When should I consider a Cardiac MRI over an Echocardiogram?

A Cardiac MRI should be considered when an echocardiogram provides insufficient information or when superior tissue characterization is needed. The ACR rates Cardiac MRI as ‘Usually appropriate’ for suspected arrhythmia and pericardial disease. It is particularly valuable for assessing the pericardium in suspected constrictive pericarditis, identifying myocardial scar or fibrosis that could be a substrate for arrhythmia, and diagnosing infiltrative cardiomyopathies (e.g., amyloidosis, sarcoidosis) that may not be apparent on echo. It is also the gold standard for quantifying ventricular volumes and function.

What is the significance of a ‘(Disagreement)’ rating for a chest X-ray in suspected arrhythmia?

The ‘May be appropriate (Disagreement)’ rating indicates that the expert panel did not reach a consensus on the utility of a chest X-ray for this specific scenario. While some experts may find it useful for assessing cardiac size and identifying gross pulmonary pathology, others may feel it has a low diagnostic yield for arrhythmia workup compared to more targeted tests like an echocardiogram or cardiac MRI, and therefore may not be routinely necessary. This rating signals that its use is a matter of clinical judgment and institutional practice.

Why are stress imaging tests ‘Usually not appropriate’ for these initial workups?

Stress imaging tests (like stress echo, stress MRI, or nuclear perfusion imaging) are primarily designed to detect inducible myocardial ischemia—the very condition that is presumed to be excluded in these ACR scenarios. Since the clinical question is not about coronary artery disease but rather about structural, valvular, pericardial, or arrhythmic causes of dyspnea, a stress component is not indicated for the initial diagnostic imaging and would provide low-yield information while adding time, cost, and complexity.

Is a CT scan a good first choice for suspected pericardial disease?

A CT scan with contrast is one of four modalities rated ‘Usually appropriate’ for suspected pericardial disease, alongside TTE, chest X-ray, and Cardiac MRI. It can be an excellent choice, particularly for evaluating pericardial thickness, calcification (a key sign of constriction), and adjacent mediastinal structures. However, it involves significant ionizing radiation. The best first choice depends on the specific clinical question and patient factors. TTE is often the fastest and most accessible initial test to screen for an effusion, while MRI may be preferred for detailed tissue characterization without radiation, and CT is superior for assessing calcification.
