It’s late in a busy shift, and you have a patient with pleuritic chest pain and tachycardia. Your differential includes pulmonary embolism (PE), but the clinical picture is ambiguous. Do you order a CT Pulmonary Angiogram (CTPA) and expose the patient to radiation and contrast, or can you safely rule it out with a lab test? Choosing the right initial imaging study is critical for timely diagnosis while minimizing unnecessary risks. The American College of Radiology (ACR) Appropriateness Criteria provide an evidence-based framework for this exact decision point, guiding clinicians toward the most effective and safest imaging pathways based on pretest probability and specific patient factors.
What Does ACR Suspected Pulmonary Embolism Cover?
The ACR Appropriateness Criteria for Suspected Pulmonary Embolism focus on the initial diagnostic imaging for adult and pediatric patients presenting with signs or symptoms suggestive of acute PE. The guidelines are stratified based on clinical pretest probability, which is typically determined using validated scoring systems like the Wells’ criteria or the revised Geneva score, often in conjunction with D-dimer testing. This framework is designed for the acute setting, such as the emergency department or inpatient service.
These criteria specifically address common clinical scenarios, including patients with low, intermediate, or high pretest probability, as well as the unique considerations for pregnant patients. The guidelines do not cover the follow-up imaging of known PE, the evaluation of chronic thromboembolic pulmonary hypertension (CTEPH), or surveillance for deep vein thrombosis (DVT) in asymptomatic patients. The focus is strictly on the initial imaging choice to confirm or exclude a new, acute pulmonary embolism.
What Imaging Should I Order for Suspected Pulmonary Embolism? Recommendations by Clinical Scenario
The optimal imaging strategy for suspected PE hinges on the patient’s pretest probability. The ACR provides clear, scenario-based recommendations to guide this critical decision.
For a patient with a low or intermediate pretest probability and a negative D-dimer, the ACR guidance is unequivocal: further imaging is Usually not appropriate. A negative D-dimer in this population has a high negative predictive value, effectively ruling out PE without the need for radiation or contrast exposure. Proceeding with studies like CTPA, V/Q scan, or MRA in this context is not supported.
When the patient has a low or intermediate pretest probability but a positive D-dimer, imaging becomes necessary. Both CTA pulmonary arteries with IV contrast and a V/Q scan are rated as Usually appropriate. The choice between them often depends on local availability, patient factors like renal function or contrast allergy (favoring V/Q), and the presence of underlying lung disease (favoring CTPA). A “triple rule out” CT is noted as May be appropriate (Disagreement), reflecting controversy over its routine use due to higher radiation and contrast loads compared to a dedicated CTPA.
In cases of high pretest probability, the diagnostic algorithm bypasses the D-dimer. Imaging is pursued directly, and again, both CTA pulmonary arteries with IV contrast and a V/Q scan are considered Usually appropriate. In this high-risk scenario, a lower extremity duplex ultrasound also becomes May be appropriate (Disagreement); if positive for DVT, it can confirm the need for anticoagulation without requiring chest imaging. A transthoracic echocardiogram is also rated May be appropriate to assess for right heart strain, which can provide prognostic information.
For a pregnant patient with suspected pulmonary embolism, the approach is multi-faceted. A chest radiograph and a US duplex Doppler of the lower extremities are both Usually appropriate as initial steps. If the duplex scan is positive, treatment can be initiated. If it is negative and suspicion remains high, both CTA pulmonary arteries with IV contrast and a V/Q scan are rated Usually appropriate. The decision involves a detailed discussion of the risks and benefits, as CTPA imparts more radiation to the maternal breast tissue while V/Q scan imparts a slightly higher (though still very low) dose to the fetus.
ACR Imaging Recommendations Table
| Clinical Scenario | Top Procedure | ACR Rating | Adult RRL | Pediatric RRL |
|---|---|---|---|---|
| Suspected pulmonary embolism. Low or intermediate pretest probability with a negative D-dimer. Initial Imaging. | No imaging indicated | Usually not appropriate | – | – |
| Suspected pulmonary embolism. Low or intermediate pretest probability with a positive D-dimer. Initial imaging. | CTA pulmonary arteries with IV contrast V/Q scan lung | Usually appropriate Usually appropriate | ☢ ☢ ☢ 1-10 mSv ☢ ☢ ☢ 1-10 mSv | ☢ ☢ ☢ ☢ 3-10 mSv [ped] ☢ ☢ ☢ 0.3-3 mSv [ped] |
| Suspected pulmonary embolism. High pretest probability. Initial Imaging. | CTA pulmonary arteries with IV contrast V/Q scan lung | Usually appropriate Usually appropriate | ☢ ☢ ☢ 1-10 mSv ☢ ☢ ☢ 1-10 mSv | ☢ ☢ ☢ ☢ 3-10 mSv [ped] ☢ ☢ ☢ 0.3-3 mSv [ped] |
| Suspected pulmonary embolism. Pregnant patient. Initial Imaging. | US duplex Doppler lower extremity Radiography chest CTA pulmonary arteries with IV contrast V/Q scan lung | Usually appropriate Usually appropriate Usually appropriate Usually appropriate | O 0 mSv ☢ <0.1 mSv ☢ ☢ ☢ 1-10 mSv ☢ ☢ ☢ 1-10 mSv | O 0 mSv [ped] ☢ <0.03 mSv [ped] ☢ ☢ ☢ ☢ 3-10 mSv [ped] ☢ ☢ ☢ 0.3-3 mSv [ped] |
Adult vs. Pediatric Suspected Pulmonary Embolism Imaging: Radiation Dose Tradeoffs
While PE is less common in children than in adults, the diagnostic principles are similar, but with a heightened emphasis on radiation safety. The As Low As Reasonably Achievable (ALARA) principle is paramount due to the increased radiosensitivity of developing tissues and the longer life expectancy over which potential stochastic effects of radiation could manifest. For pediatric patients, the ACR guidelines often highlight different relative radiation levels (RRLs) for the same study compared to adults.
For instance, a V/Q scan in a pediatric patient carries an RRL of ☢ ☢ ☢ (0.3-3 mSv), which is a lower effective dose range than the adult equivalent (☢ ☢ ☢ 1-10 mSv). Conversely, a CTPA is rated ☢ ☢ ☢ ☢ (3-10 mSv) for pediatrics, a higher tier than the adult rating of ☢ ☢ ☢ (1-10 mSv), reflecting the greater relative impact of the dose. This difference can make V/Q scans a more attractive option in children with a normal chest radiograph, assuming institutional expertise in pediatric nuclear medicine is available. The decision must always be individualized, weighing the diagnostic urgency against the long-term risks of cumulative radiation exposure.
Imaging Protocol Details for Suspected Pulmonary Embolism
Once you’ve decided on the right study based on the ACR criteria, ensuring it is performed correctly is the next critical step. The diagnostic accuracy of a CTPA or lower extremity ultrasound depends heavily on the technical protocol, including contrast timing, scan parameters, and interpretation standards. Our protocol guides provide detailed, scannable references for the key studies recommended in these guidelines.
Tools to Help You Order the Right Study
Navigating imaging guidelines in real-time can be challenging. To streamline the process of applying evidence-based medicine at the point of care, GigHz offers a suite of integrated tools designed for busy clinicians.
The ACR Appropriateness Criteria Lookup provides rapid access to the full library of ACR guidelines, allowing you to quickly find recommendations for hundreds of clinical scenarios beyond suspected pulmonary embolism. It helps ensure your imaging orders are always aligned with the latest evidence.
For detailed technical specifications on how to perform a recommended study, the Imaging Protocol Library offers standardized, easy-to-follow protocols for a wide range of CT, MRI, and ultrasound examinations. This resource is invaluable for trainees and technologists aiming for consistent, high-quality imaging.
When discussing radiation exposure with patients, especially in sensitive populations like pediatric or pregnant patients, the Radiation Dose Calculator is an essential communication aid. It helps quantify and explain the dose associated with common imaging studies, facilitating informed shared decision-making.
Frequently Asked Questions
When is a V/Q scan preferred over a CTPA for suspected PE?
A V/Q scan is often preferred over a CTPA in several key situations: patients with severe iodinated contrast allergy, those with significant renal insufficiency (as V/Q scans do not use iodinated contrast), and in young patients, particularly young women, to minimize radiation dose to the breast tissue. A V/Q scan requires a normal or near-normal baseline chest radiograph for accurate interpretation.
Is a D-dimer always necessary before imaging for suspected PE?
No. In patients with a high pretest probability for pulmonary embolism (e.g., based on Wells’ criteria), the D-dimer test has limited value. Its specificity is low, and it is likely to be positive anyway. In these high-risk cases, the ACR guidelines support proceeding directly to definitive imaging like CTPA or a V/Q scan, as a negative D-dimer would not be sufficient to rule out PE.
What is a “triple rule-out” CT, and why is it sometimes inappropriate?
A “triple rule-out” CT is a specialized CT angiogram protocol designed to simultaneously evaluate for three major causes of acute chest pain: pulmonary embolism, aortic dissection, and acute coronary syndrome. While it seems efficient, the ACR panel notes disagreement on its appropriateness. The protocol requires a higher radiation dose and a larger volume of IV contrast than a standard CTPA. It is often considered inappropriate when the clinical suspicion for aortic dissection or significant coronary artery disease is very low, as it exposes the patient to unnecessary risk for a low-yield investigation.
How should I approach suspected PE in a pregnant patient?
The approach should be stepwise. First, use a validated clinical decision rule. If suspicion remains, the ACR considers a lower extremity compression ultrasound a “Usually appropriate” first imaging step. If the ultrasound is positive for DVT, the patient can be treated for VTE without further imaging. If the ultrasound is negative but clinical suspicion is still high, a chest radiograph should be performed. If the radiograph is normal, either a V/Q scan or CTPA is appropriate, and the choice should be guided by a discussion with the patient about the relative risks (V/Q: slightly more fetal radiation; CTPA: more maternal breast radiation).
What if my patient has contraindications to both CT contrast and a V/Q scan?
This is a challenging clinical scenario. Magnetic Resonance Angiography (MRA) of the pulmonary arteries is rated as “May be appropriate” and can be a valuable alternative as it avoids both ionizing radiation and iodinated contrast (though it requires gadolinium). Another strategy is to rely on indirect evidence; a comprehensive bilateral lower extremity duplex ultrasound can be performed. If a DVT is found, this is sufficient evidence to initiate anticoagulation, treating the patient for venous thromboembolism without directly visualizing the PE.
