Cardiac Imaging

Which Imaging Study Is Best for Suspected Congenital Heart Disease in an Adult?

·
Which Imaging Study Is Best for Suspected Congenital Heart Disease in an Adult?

An otherwise healthy 42-year-old presents to your clinic for a routine physical. On examination, you note a subtle fixed, split S2 and a soft systolic ejection murmur at the upper left sternal border. The patient is asymptomatic, but these findings raise your suspicion for a previously undiagnosed congenital heart defect, most likely an atrial septal defect. You need to decide on the optimal imaging strategy to confirm the diagnosis, assess its hemodynamic significance, and guide further management. This article details the clinical workflow for an adult with known or suspected congenital heart disease, explaining why the American College of Radiology (ACR) rates Transesophageal Echocardiography (TEE) as Usually Appropriate for this scenario.

Who Fits This Clinical Scenario?

This guidance applies to adult patients (typically over 18 years old) presenting with new signs or symptoms suggestive of a previously undiagnosed or uncharacterized congenital heart defect. This includes clinical findings such as a new heart murmur, unexplained arrhythmia, exertional dyspnea, cyanosis, or evidence of a paradoxical embolism like a cryptogenic stroke. It also covers patients with a known congenital condition from childhood that was never fully characterized or has been lost to follow-up, and now requires a definitive anatomic and functional assessment.

This workflow is distinct from other clinical situations. It does not apply to:

  • Routine surveillance of known, stable disease: A patient with a fully characterized and repaired tetralogy of Fallot undergoing their scheduled annual Cardiac MRI follows a different surveillance protocol.
  • Acute chest pain syndromes: An adult presenting with acute chest pain where acute coronary syndrome is the primary concern would first undergo a workup focused on coronary artery disease, not congenital defects.
  • Primary valvular disease workup: While some congenital defects involve valves (e.g., bicuspid aortic valve), a workup initiated solely for progressive, known aortic stenosis in an older adult is managed as a valvular disease pathway.

The focus here is on the initial diagnostic evaluation when the possibility of a structural congenital defect is first raised in an adult.

What Diagnoses Are You Working Up in This Scenario?

While many complex congenital heart diseases (CHD) are diagnosed in infancy, several can remain clinically silent until adulthood. The imaging workup is designed to identify these specific conditions and assess their impact on cardiac structure and function.

Atrial Septal Defect (ASD): This is the most common congenital heart defect to first present in adulthood. A left-to-right shunt through an ASD can lead to right ventricular volume overload, pulmonary hypertension, and arrhythmias over decades. The classic physical exam finding is a fixed, split second heart sound.

Patent Foramen Ovale (PFO): While a common finding, a PFO becomes clinically significant as a potential conduit for paradoxical emboli, leading to cryptogenic stroke or transient ischemic attack. Its detection is a primary goal in young adults with unexplained neurologic events.

Ventricular Septal Defect (VSD): Smaller, restrictive VSDs may not cause significant symptoms in childhood and can be discovered incidentally in adults due to a harsh holosystolic murmur. Larger defects are less likely to go undiagnosed but can present with signs of heart failure or pulmonary hypertension.

Bicuspid Aortic Valve (BAV): One of the most common congenital cardiac anomalies, BAV often presents in middle age with progressive aortic stenosis or regurgitation. It is also associated with aortopathy, including aortic root and ascending aortic aneurysms, which requires careful surveillance.

Coarctation of the Aorta: A narrowing of the aorta, typically near the ductus arteriosus, can present in adults with hypertension (particularly with a blood pressure discrepancy between the upper and lower extremities), headache, or heart failure. It is often missed if lower extremity pressures are not checked.

Why Is Transesophageal Echocardiography a Recommended Study for This Presentation?

For an initial evaluation of suspected congenital heart disease in an adult, both Transthoracic Echocardiography (TTE) and Transesophageal Echocardiography (TEE) are rated as Usually Appropriate by the ACR. TTE is almost always the first imaging test performed due to its non-invasive nature and wide availability. However, TEE is a crucial, highly-rated component of the workup, often providing the definitive diagnosis when TTE is inconclusive or when higher detail is required.

TEE involves placing an ultrasound probe in the esophagus, which provides unparalleled high-resolution images of posterior cardiac structures. This is its key advantage over TTE. For the differential diagnoses in this scenario, TEE is particularly powerful for:

  • Visualizing the Atrial Septum: TEE offers superior imaging of the interatrial septum, making it the gold standard for diagnosing, localizing, and characterizing ASDs (e.g., secundum, primum, sinus venosus) and PFOs. A saline contrast “bubble study” performed during TEE is highly sensitive for detecting right-to-left shunting.
  • Assessing Pulmonary Veins: A sinus venosus ASD is associated with anomalous pulmonary venous return, a diagnosis that is difficult with TTE but well-visualized on TEE.
  • Evaluating Valvular Detail: It provides exquisite detail of valve leaflet morphology and function, critical for assessing conditions like a bicuspid aortic valve or mitral valve clefts associated with ASDs.

Both TTE and TEE are radiation-free procedures (O 0 mSv). While TEE is minimally invasive and requires sedation, its diagnostic yield for specific questions like shunt detection often justifies its use after an initial TTE.

Other imaging modalities are also rated Usually Appropriate but serve different roles. Cardiac MRI (CMR) is an excellent problem-solving tool, providing precise quantification of ventricular volumes, ejection fraction, and shunt fractions (Qp:Qs ratio). It is the gold standard for assessing the right ventricle and can visualize complex anatomy or anomalous venous connections that may be missed on echo. Cardiac CT/CTA (☢☢☢ 1-10 mSv to ☢☢☢☢ 10-30 mSv) is less frequently used for the initial diagnosis of intracardiac shunts but is invaluable for assessing the aorta (for coarctation or aneurysm) and the coronary arteries.

What’s Next After Transesophageal Echocardiography? Downstream Workflow

The results of the echocardiographic evaluation will directly guide the subsequent clinical pathway. The goal is to move from anatomic diagnosis to a functional assessment that informs the need for intervention.

If the study is positive for a significant defect:
If TEE confirms a hemodynamically significant ASD (e.g., with evidence of right ventricular volume overload), the next step is referral to a cardiologist specializing in adult congenital heart disease (ACHD). Further evaluation may include cardiac catheterization to directly measure pressures and confirm the shunt size before considering percutaneous device closure.

If the study is negative but clinical suspicion remains high:
If both TTE and TEE are negative for a shunt or other clear structural defect but symptoms (like profound desaturation with exertion) persist, the workup is not over. The next logical step is often a Cardiac MRI. CMR can detect extracardiac shunts, anomalous pulmonary venous drainage not seen on TEE, and provide highly accurate functional data that might reveal a subtle cardiomyopathy or right ventricular dysfunction.

If the study is indeterminate:
Occasionally, TEE may be technically limited. In such cases, or if the findings are ambiguous, Cardiac MRI is the preferred next test to clarify the anatomy and physiology without exposing the patient to ionizing radiation. For suspected aortic pathology like coarctation, a CT Angiography or MR Angiography of the chest would be the definitive next step.

Pitfalls to Avoid (and When to Get Help)

Navigating the workup for adult congenital heart disease requires careful consideration to avoid common diagnostic traps.

  • Stopping at a “Normal” TTE: A standard transthoracic echo can miss small ASDs, PFOs, and anomalous pulmonary veins. If clinical suspicion is moderate to high, proceeding to a TEE with a bubble study is essential.
  • Ignoring the Great Vessels: A cardiac-focused workup can sometimes overlook the aorta. Always consider coarctation in an adult with hypertension, and remember the strong association between bicuspid aortic valve and thoracic aortic aneurysm.
  • Underestimating Hemodynamics: The presence of a defect is only part of the story. The key question is its hemodynamic significance. Failing to assess for right ventricular enlargement, pulmonary hypertension, or shunt size can lead to undertreatment.
  • Patient Selection for TEE: Remember that TEE is an invasive procedure requiring sedation. Assess for contraindications such as esophageal strictures, varices, or an unwillingness to undergo the procedure.

If imaging reveals complex anatomy, significant pulmonary hypertension, or multi-valvular disease, it is critical to escalate care by referring the patient to a specialized ACHD center for multidisciplinary management.

Related ACR Topics and Tools

For a comprehensive overview of all clinical scenarios related to adult congenital heart disease, please consult the main ACR topic guide. The following GigHz tools can also support your clinical decision-making and patient conversations.

Frequently Asked Questions

Isn’t a regular transthoracic echocardiogram (TTE) the first test I should order?

Yes, absolutely. A Transthoracic Echocardiogram (TTE) is the initial, non-invasive screening test for virtually all cases of suspected congenital heart disease. This article highlights Transesophageal Echocardiography (TEE) because it is also rated ‘Usually Appropriate’ and often serves as the definitive diagnostic step when TTE is non-diagnostic or when superior visualization of specific structures, like the atrial septum, is required.

When should I choose Cardiac MRI over TEE for suspected congenital heart disease?

Choose Cardiac MRI when the primary question involves quantifying ventricular size and function (especially the right ventricle), measuring shunt fraction (Qp:Qs), or when you have a strong suspicion for anomalous pulmonary venous connections, which are superbly visualized by MRI. It is also the preferred follow-up test for assessing the right ventricle after a defect has been repaired.

What is a ‘bubble study’ and when is it needed?

A bubble study involves injecting agitated saline into a peripheral vein during an echocardiogram (either TTE or TEE). The microbubbles are too large to pass through the pulmonary capillaries, so if they appear in the left side of the heart, it confirms the presence of a right-to-left shunt, such as through an ASD or PFO. It is essential for a complete evaluation when a shunt is suspected.

Does this guidance apply to a patient with a known bicuspid aortic valve?

Yes, a bicuspid aortic valve is a form of congenital heart disease. This guidance applies to its initial diagnosis. However, once diagnosed, the patient enters a surveillance pathway focused on monitoring valve function (stenosis/regurgitation) and assessing for associated aortopathy (aortic aneurysm), which often involves serial echocardiograms and periodic CT or MR angiography of the aorta.

If I suspect coarctation of the aorta, is echocardiography still the right first test?

While TTE can sometimes visualize the aortic arch and suggest coarctation (e.g., by showing increased flow velocities), it is often not definitive in adults. The gold standard for diagnosing and characterizing aortic coarctation is either CT Angiography (CTA) or MR Angiography (MRA) of the chest, which provides complete, detailed visualization of the entire thoracic aorta.

Reviewed by Pouyan Golshani, MD, Interventional Radiologist — May 26, 2026
