It’s late in your shift, and a patient presents with acute shoulder pain after a fall. They have limited range of motion and point tenderness over the greater tuberosity. You need to rule out a fracture, but you also suspect a rotator cuff injury. Do you start with a radiograph, go straight to ultrasound, or order an MRI? Choosing the right initial and subsequent imaging is critical for accurate diagnosis, cost-effective care, and minimizing unnecessary radiation. This guide decodes the American College of Radiology (ACR) Appropriateness Criteria for acute shoulder pain to help you make the right call, every time.
What Does ACR Acute Shoulder Pain Cover?
The ACR Appropriateness Criteria for Acute Shoulder Pain provide evidence-based guidelines for imaging adult patients with new-onset or recent-onset shoulder pain. The scope is broad, covering various potential etiologies including trauma, instability, and suspected soft tissue injuries like rotator cuff or labral tears. These criteria are designed to guide the initial imaging workup and subsequent steps based on clinical findings and the results of preliminary studies.
This topic specifically addresses acute presentations. It does not cover imaging for chronic shoulder pain (pain lasting more than 6 weeks), evaluation of suspected glenohumeral or acromioclavicular arthritis, postoperative imaging, or suspected infection or malignancy, which are addressed in separate ACR guidelines. The focus here is on the immediate diagnostic pathway for a patient presenting with a new shoulder complaint.
What Imaging Should I Order for Acute Shoulder Pain? Recommendations by Clinical Scenario
The optimal imaging pathway for acute shoulder pain depends entirely on the clinical context, including the mechanism of injury and physical examination findings. The ACR provides specific recommendations for common scenarios.
For nearly all cases of adult acute shoulder pain, regardless of etiology, initial imaging begins with radiography. The ACR rates Radiography shoulder as Usually appropriate. This is the essential first step to evaluate for fracture, dislocation, or other obvious osseous abnormalities. All other advanced imaging modalities, including MRI, CT, and ultrasound, are rated Usually not appropriate for the initial, undifferentiated workup.
If you suspect an occult fracture and initial radiographs are negative or indeterminate, the next step is advanced imaging. Both MRI shoulder without IV contrast and CT shoulder without IV contrast are rated Usually appropriate. MRI offers superior sensitivity for detecting bone marrow edema associated with non-displaced fractures and evaluating for concurrent soft tissue injury. CT provides excellent detail of cortical bone and is often faster and more accessible in an emergency setting.
When radiographs are positive for a proximal humerus, scapular, or clavicle fracture, further characterization is often needed for surgical planning. In this scenario, CT shoulder without IV contrast is rated Usually appropriate to delineate fracture patterns, comminution, and articular involvement. An MRI shoulder without IV contrast May be appropriate to assess for associated soft tissue injuries, such as rotator cuff tears, which can accompany these fractures.
For patients with a history or exam consistent with dislocation or instability, an MRI shoulder without IV contrast is Usually appropriate as the next step after radiographs. It is excellent for identifying associated labral tears (e.g., Bankart lesions), humeral head impression fractures (Hill-Sachs lesions), and rotator cuff injuries. Both MR arthrography shoulder and CT shoulder without IV contrast are rated May be appropriate (Disagreement), reflecting variability in practice and the specific clinical question being asked.
If the physical examination is specifically consistent with a labral tear and radiographs are negative, more detailed imaging is warranted. MR arthrography shoulder, MRI shoulder without IV contrast, and CT arthrography shoulder are all rated Usually appropriate. MR arthrography is often considered the most sensitive test for detecting and characterizing labral pathology due to joint distention from the injected contrast.
Finally, when the clinical exam points toward a rotator cuff tear and radiographs are negative, both US shoulder and MRI shoulder without IV contrast are rated Usually appropriate. Ultrasound is a dynamic, cost-effective, and highly accurate modality for diagnosing full-thickness rotator cuff tears when performed by an experienced operator. MRI provides a more comprehensive evaluation of the rotator cuff muscles and tendons, as well as other intra-articular structures.
ACR Imaging Recommendations Table
| Clinical Scenario | Top Procedure | ACR Rating | Adult RRL | Pediatric RRL |
|---|---|---|---|---|
| Adult. Acute shoulder pain. Any etiology. Initial imaging. | Radiography shoulder | Usually appropriate | ☢ <0.1 mSv | |
| Adult. Acute shoulder pain. Suspect occult fracture. Radiographs negative or indeterminate. Next imaging study. | MRI shoulder without IV contrast | Usually appropriate | O 0 mSv | O 0 mSv [ped] |
| Adult. Acute shoulder pain. Radiographs positive for proximal humerus, scapular, or clavicle fracture. Next imaging study. | CT shoulder without IV contrast | Usually appropriate | ☢ ☢ ☢ 1-10 mSv | |
| Adult. Acute shoulder pain. History or physical examination consistent with dislocation or instability. Radiographs positive, negative, or indeterminate. Next imaging study. | MRI shoulder without IV contrast | Usually appropriate | O 0 mSv | O 0 mSv [ped] |
| Adult. Acute shoulder pain. Physical examination consistent with labral tear. Radiographs negative or indeterminate. Next imaging study. | MR arthrography shoulder | Usually appropriate | O 0 mSv | O 0 mSv [ped] |
| Adult. Acute shoulder pain. Physical examination consistent with rotator cuff tear. Radiographs negative or indeterminate. Next imaging study. | US shoulder | Usually appropriate | O 0 mSv | O 0 mSv [ped] |
Adult vs. Pediatric Acute Shoulder Pain Imaging: Radiation Dose Tradeoffs
While the ACR criteria for this topic are primarily focused on adults, the principles of radiation safety are paramount when imaging pediatric patients. The concept of As Low As Reasonably Achievable (ALARA) guides imaging choices in children, who are more sensitive to the long-term effects of ionizing radiation. For shoulder imaging, many of the most useful modalities, such as MRI and ultrasound, involve no ionizing radiation (rated O 0 mSv) and are therefore equally safe for adults and children.
However, when a CT scan is necessary—for instance, to evaluate a complex fracture—the radiation dose becomes a key consideration. The ACR provides pediatric-specific Relative Radiation Level (RRL) estimates where applicable. For example, an FDG-PET/CT scan carries an RRL of ☢ ☢ ☢ ☢ (10-30 mSv) in adults but is estimated at ☢ ☢ ☢ ☢ (3-10 mSv [ped]) in children, reflecting dose-reduction techniques used in pediatric protocols. The decision to use an imaging modality with ionizing radiation in a child requires a careful weighing of the diagnostic benefit against the potential long-term risks of cumulative radiation exposure.
Imaging Protocol Details for Acute Shoulder Pain
Once you’ve decided on the right study based on the ACR criteria, ensuring it’s performed correctly is the next critical step. The specific imaging protocol—including patient positioning, sequence selection for MRI, or transducer choice for ultrasound—directly impacts diagnostic quality. Our protocol guides provide detailed, practical information for the studies recommended above.
Tools to Help You Order the Right Study
Navigating imaging guidelines and radiation safety can be complex. GigHz offers a suite of free reference tools designed to support clinical decision-making at the point of care.
The ACR Appropriateness Criteria Lookup provides a searchable interface to the complete ACR guidelines, allowing you to quickly find recommendations for hundreds of clinical scenarios beyond acute shoulder pain.
Our Imaging Protocol Library offers detailed, step-by-step protocols for a wide range of CT, MRI, and ultrasound examinations, helping ensure you not only order the right test but that it’s performed to the highest standard.
To help with patient communication and tracking cumulative exposure, the Radiation Dose Calculator allows you to estimate effective dose for various imaging studies based on the ACR’s RRL system.
Frequently Asked Questions
Why are radiographs the first step for most acute shoulder pain presentations?
Radiographs (X-rays) are the recommended initial imaging study because they are fast, widely available, inexpensive, and effective at identifying significant osseous pathology. They can quickly diagnose or rule out fractures, dislocations, and calcific tendonitis, which are common causes of acute shoulder pain. Starting with radiographs prevents the unnecessary use of more complex and expensive imaging like MRI or CT for straightforward cases.
When is an MR arthrogram better than a standard non-contrast MRI for shoulder pain?
An MR arthrogram, which involves injecting contrast directly into the glenohumeral joint, is superior to a standard MRI for evaluating intra-articular structures, particularly the labrum and articular cartilage. The joint distention from the contrast provides better visualization of subtle labral tears (like SLAP or Bankart lesions) and delamination of cartilage. It is rated as ‘Usually appropriate’ specifically when there is a high clinical suspicion for a labral tear.
Is ultrasound a good alternative to MRI for a suspected rotator cuff tear?
Yes, for suspected rotator cuff tears, ultrasound is considered ‘Usually appropriate’ and is an excellent alternative to MRI. It is highly accurate for detecting full- and partial-thickness tears of the rotator cuff tendons, especially the supraspinatus. Advantages include lower cost, no contraindications for patients with metallic implants or claustrophobia, and the ability to perform dynamic imaging. However, its accuracy is highly dependent on the skill of the operator, and it provides a less comprehensive view of bone and other intra-articular structures compared to MRI.
What is the primary role of CT in evaluating acute shoulder pain?
The primary role of CT in the acute setting is to evaluate complex fractures. After a fracture is identified on initial radiographs, a non-contrast CT is ‘Usually appropriate’ to better define the fracture pattern, assess the degree of displacement and comminution, and evaluate for intra-articular extension. This level of detail is often crucial for orthopedic surgical planning. CT is generally not the first choice for evaluating soft tissues like tendons or labrum.
Why are most contrast-enhanced CT and MRI studies rated ‘Usually not appropriate’?
For the majority of acute shoulder pain scenarios, intravenous (IV) contrast is not necessary and does not add significant diagnostic information. Non-contrast MRI provides excellent soft tissue contrast to evaluate tendons, ligaments, and bone marrow. Non-contrast CT is sufficient for characterizing fractures. IV contrast is typically reserved for specific indications not covered in this acute guideline, such as suspected tumor, infection (abscess), or specific vascular concerns.
Reviewed by Pouyan Golshani, MD, Interventional Radiologist — May 12, 2026
