What Imaging Comes Next for a Painful Shoulder Arthroplasty Suspected of Infection?

·
What Imaging Comes Next for a Painful Shoulder Arthroplasty Suspected of Infection?

A 68-year-old patient returns to your clinic two years after a primary total shoulder arthroplasty, complaining of progressive, deep-seated pain and new-onset stiffness. There is mild warmth and erythema over the anterior shoulder. Inflammatory markers are elevated, and while initial radiographs show the components are in a stable position, you cannot exclude a periprosthetic joint infection (PJI). The critical decision is which study to order next to confirm or exclude this serious diagnosis before committing the patient to a major surgical revision. This article provides a focused workflow for this exact scenario, guiding the choice for additional imaging. According to the American College of Radiology (ACR), for a symptomatic patient with a primary shoulder arthroplasty where infection is not excluded, the next step of Image-guided aspiration shoulder is rated Usually Appropriate.

Who Fits This Clinical Scenario?

This guidance is specifically for a patient who meets a precise set of criteria. The workflow applies when your patient has a primary (not revision) shoulder arthroplasty, is currently symptomatic (e.g., pain, decreased range of motion, swelling, or warmth), and has already undergone initial evaluation with radiographs. Most importantly, periprosthetic joint infection (PJI) is a key consideration in the differential diagnosis based on clinical signs or elevated inflammatory markers (like Erythrocyte Sedimentation Rate or C-Reactive Protein).

This article does not apply to several similar-but-distinct clinical situations, which have their own evaluation pathways:

  • Routine asymptomatic follow-up: If the patient has no symptoms and is being seen for routine surveillance, additional imaging is typically not warranted.
  • Infection is definitively excluded: If clinical and laboratory findings have confidently ruled out infection, the workup shifts. The primary suspicion becomes mechanical loosening or soft tissue pathology, which follows a different ACR variant.
  • Initial imaging has not been performed: This workflow assumes standard radiographs have already been obtained and reviewed. Radiographs are the essential first step in every symptomatic arthroplasty evaluation.

What Diagnoses Are You Working Up in This Scenario?

When a patient with a shoulder replacement presents with pain and suspicion of infection, the differential diagnosis is narrow but the stakes are high. The imaging and procedural choices are designed to differentiate between infectious and non-infectious causes of implant failure.

Periprosthetic Joint Infection (PJI)
This is the most urgent and consequential diagnosis to establish. PJI is a devastating complication that requires prolonged antibiotic therapy and often complex, staged surgical revision. Because its clinical presentation can be subtle and overlap significantly with other conditions, obtaining a direct sample of synovial fluid for culture and cell count is the cornerstone of diagnosis.

Aseptic Loosening
This is the most common long-term failure mechanism for shoulder arthroplasty. It is a non-infectious, inflammatory response to microscopic wear debris from the implant’s bearing surfaces. The resulting bone loss (osteolysis) around the components can cause pain and instability. Clinically and on radiographs, it can be indistinguishable from septic (infectious) loosening.

Component Failure or Malposition
Less commonly, symptoms can arise from a mechanical issue with the implant itself, such as subsidence of the humeral stem, fracture of the glenoid component, or dissociation of modular parts. While often visible on radiographs, subtle changes may require advanced imaging.

Rotator Cuff Tear or Other Soft Tissue Pathology
In both anatomic and reverse total shoulder arthroplasty, the health of the surrounding soft tissues, particularly the rotator cuff and deltoid, is critical for function. A new tear or worsening tendinopathy can be a source of pain, but these are diagnoses of exclusion after PJI has been ruled out.

Why Is Image-Guided Aspiration the Recommended Next Step?

When infection is a possibility in a symptomatic shoulder arthroplasty, the diagnostic goal shifts from simply visualizing anatomy to obtaining a definitive microbiological diagnosis. This is why the ACR rates Image-guided aspiration shoulder as Usually Appropriate. It is a diagnostic procedure, not just an imaging study. Aspiration directly samples the joint fluid, allowing for cell count, differential, crystal analysis, and, most critically, aerobic and anaerobic cultures. This information is essential for confirming PJI and cannot be obtained from non-invasive cross-sectional imaging.

Alternative imaging studies are rated lower for this specific question, primarily because they can only show secondary, non-specific signs of inflammation or infection.

  • MRI shoulder without and with IV contrast is rated May be appropriate. While modern metal artifact reduction sequence (MARS) protocols have improved image quality, significant artifact from the implant often remains, obscuring periprosthetic tissues. MRI can identify fluid collections, synovitis, or abscesses, but it cannot reliably distinguish septic from aseptic inflammation. Its main role is in evaluating soft tissue structures like the rotator cuff, a task best performed after infection has been excluded by aspiration.
  • CT shoulder (with or without contrast) is rated Usually not appropriate. While CT with MARS is excellent for evaluating component position, osteolysis, and bone stock, it offers poor soft tissue contrast. It is not sensitive for detecting the synovitis or fluid collections that are hallmarks of early infection.
  • Nuclear medicine scans (e.g., 3-phase bone scan combined with a WBC scan) are rated May be appropriate. These studies are highly sensitive for inflammation but often lack specificity, as increased uptake can be seen in both PJI and aseptic loosening. They also involve a significant radiation dose (☢☢☢☢ 10-30 mSv) and are logistically complex.

The choice of guidance for the aspiration—ultrasound or fluoroscopy—depends on institutional preference and operator experience. Ultrasound is radiation-free (O 0 mSv) and excellent for visualizing and targeting fluid collections, while fluoroscopy confirms an intra-articular needle position relative to the hardware. The primary goal is to obtain an adequate fluid sample for analysis. If you are considering alternatives like MRI after a non-diagnostic aspiration, understanding the technical details is crucial. Once you’ve decided on MRI shoulder without IV contrast, our protocol guide covers the technique, contrast, and reading principles: MRI Shoulder Without Contrast.

What’s Next After Image-Guided Aspiration? Downstream Workflow

The results of the shoulder aspiration create a clear branch point in the patient’s management plan. The downstream workflow depends entirely on whether the fluid analysis confirms or refutes the presence of infection.

If the Aspiration is POSITIVE for Infection
A positive result, based on established criteria (e.g., Musculoskeletal Infection Society criteria for PJI, involving cell count and culture results), confirms the diagnosis. At this point, further diagnostic imaging is generally unnecessary. The patient should be referred urgently to an orthopedic surgeon specializing in revision arthroplasty. The standard of care is typically a two-stage revision, involving removal of the implants, placement of an antibiotic spacer, a prolonged course of intravenous antibiotics, and subsequent reimplantation surgery.

If the Aspiration is NEGATIVE for Infection
A negative aspiration makes PJI much less likely, shifting the diagnostic focus toward mechanical or non-infectious inflammatory causes. The workup now aligns with a different clinical scenario: “Symptomatic patient with a primary shoulder arthroplasty, infection excluded.” The next step may involve advanced imaging to assess for aseptic loosening, component wear, or rotator cuff pathology. A CT with metal artifact reduction may be ordered to evaluate bone-implant interfaces, or an MRI with MARS may be used to assess the soft tissues.

If the Aspiration is INDETERMINATE or a “Dry Tap”
An equivocal result (e.g., borderline cell count, contaminant on culture) or failure to obtain fluid presents a diagnostic challenge. The first step is often to repeat the aspiration, perhaps with a different guidance modality. If suspicion for infection remains high despite a negative or indeterminate aspirate, advanced imaging like a combined labeled WBC/sulfur colloid marrow scan may be considered to look for discordant uptake suggestive of infection.

Pitfalls to Avoid (and When to Get Help)

Navigating the workup for a painful shoulder arthroplasty requires careful attention to detail to avoid common errors that can delay diagnosis or lead to incorrect treatment.

  • Aspirating After Antibiotics: The most critical pitfall is performing a joint aspiration after the patient has been started on antibiotics. This can sterilize the joint fluid, leading to a false-negative culture and a missed diagnosis of PJI. If clinically safe, antibiotics should be held for at least two weeks prior to aspiration.
  • Incomplete Sample Analysis: Simply sending the fluid for “culture” is insufficient. The order must explicitly include a synovial fluid cell count with differential, crystal analysis (to rule out crystalline arthropathy), and cultures for both aerobic and anaerobic organisms.
  • Misinterpreting Imaging: Do not rely on MRI or CT findings to rule out infection. Significant periprosthetic fluid and synovitis can be seen in both aseptic and septic processes. Aspiration remains the diagnostic standard.

If the patient presents with systemic signs of sepsis (fever, tachycardia, hypotension) or a draining sinus tract communicating with the joint, this constitutes a surgical emergency. Escalate immediately to an orthopedic surgeon for urgent surgical irrigation and debridement.

Related ACR Topics and Tools

This article focuses on one specific clinical scenario. For a comprehensive overview of all variants and imaging modalities related to shoulder arthroplasty, or to explore the tools used in this workflow, please refer to the following resources.

Frequently Asked Questions

Why not just order an MRI first to see if there is an infection?

While an MRI with metal artifact reduction sequences can show fluid collections and inflammation around the implant, these findings are non-specific. They cannot reliably distinguish between an infection (septic) and a sterile inflammatory process like aseptic loosening. Image-guided aspiration is more direct and provides a definitive microbiological diagnosis, which is essential for guiding treatment.

What should I do if the aspiration attempt results in a ‘dry tap’ with no fluid return?

A dry tap can occur if the needle is not in the ideal position or if there is very little joint fluid. The first step is to reposition the needle under imaging guidance. If still unsuccessful, a saline lavage (injecting and re-aspirating sterile saline) can be attempted. If no sample can be obtained and suspicion for infection remains high, you may need to proceed with advanced imaging (like a WBC scan) or refer for a surgical biopsy.

Should the patient stop taking antibiotics before the shoulder aspiration?

Yes, whenever clinically safe. Administering antibiotics before aspiration can sterilize the joint fluid and lead to a false-negative culture. The standard recommendation is to withhold antibiotics for at least two weeks prior to the procedure. This decision should always be made in consultation with the treating orthopedic surgeon or an infectious disease specialist.

Is ultrasound guidance better than fluoroscopy for the aspiration?

Both are effective guidance modalities. Ultrasound is often preferred as it involves no ionizing radiation and can directly visualize and target fluid pockets. Fluoroscopy is excellent for confirming that the needle tip is intra-articular relative to the metallic components. The best choice often depends on the radiologist’s expertise and institutional preference.

What if the initial radiographs already show obvious signs of component loosening?

Even with clear radiographic evidence of loosening (e.g., radiolucent lines at the bone-implant interface), an aspiration is still critical. Septic loosening and aseptic loosening can appear identical on X-rays. Since the treatment for infection (staged revision, long-term antibiotics) is drastically different and more complex than for aseptic failure, ruling out PJI with an aspiration is a mandatory step before any revision surgery is planned.

Reviewed by Pouyan Golshani, MD, Interventional Radiologist — May 26, 2026
